Summary of Contents for Altronix PT72724
- Page 1 Installation/ Programming Guide for PT72724 365 Day 24 Hr. Timer/Controller...
- Page 2 Relay OFF - De-energizes the relay until a relay ON event is detected Relay ON - Energizes the relay until a relay OFF event is detected. IIPT2724-Rev. 060500 Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice.
- Page 3 When this terminal is connected to DC neg. (-) the “First Man in” feature is enabled. Both relays will remain in their present position until this connection is terminated. At that time relays will resume normal operation and latest scheduled events will occur. Fig. 1 ALTRONIX CORP. BKLYN, N.Y. 11220 MADE IN USA PT 2724...
- Page 4 UP and DOWN keys can be used to select data entries. After scrolling to the correct entry, depress ENTER to accept. SW2 clip SW Selects tandem or individual relay operation. SW3 slide SW Selects channel to be programmed. Programming Instructions: The flashing cursor denotes location of data entry selection to be made.
- Page 5 Note: When it is required to have the same event repeated on two (2) or more consecutive days of the week, the event must be programmed as a block by selecting BK in the day field. BK 00:00 Note: To program the consecutive days of the week refer to Setting Block Event (weekly repeat) and Daylight Savings Time - section C1 below.
- Page 6 E. Setting Holiday Dates: Select chanel A or B by moving slide switch SW3 to appropiate position. Note: Channel cannot be changed in the middle of programming events. To change channels you must exit programming then change channel switch position then enter program mode again. It is now necessary to assign these holiday events specific calendar dates which they are to occur.
- Page 7 Customer Event Log Event # Relay # Day/Block Holiday Dates Event Type MEMBER Altronix Corp. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A.
