Polargos Simple Move 101 Manual

Cantilever gate drive unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Simple Move
101
EN
CANTILEVER GATE DRIVE UNIT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Simple Move 101 and is the answer not in the manual?

Questions and answers

Related Manuals for Polargos Simple Move 101

Summary of Contents for Polargos Simple Move 101

  • Page 1 Simple Move CANTILEVER GATE DRIVE UNIT...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ................3 SAFETY PRINCIPLES ...............3 PRODUCT DESCRIPTION ..............4 Components of the set Gate dimensions and maximum weight Drive dimensions (in mm) Pictorial view of installation Technical data PRELIMINARY OPERATIONS ............7 Checks before installation Required tools Preliminary wiring system Safety rules 1.

  • Page 3: Introduction

    INTRODUCTION POLARGOS is a Polish manufacturer of housing and industrial fence systems as well as other steel products that has been operating on the market since 1994. Due to their many years of experience as well as production and marketing facilities, POLARGOS manufactures products for numerous domestic and foreign customers.

  • Page 4: Product Description

    Double-thread screw 10x15 mm Pin 10x60 S12 POLARGOS hereby declares that this product conforms to the basic requirements and other relevant regulations of the Directive 1999/5/CE. The Declaration of Conformity is available at www.polargos.eu This product is accepted for use in European Union and Switzerland..

  • Page 5: Gate Dimensions And Maximum Weight

    Light sensor Light The electronic module of the drive is equipped with a light sensor that detects the sensor presence or absence of the shield. Thanks to this function, the setting mode is available only with the shield removed. If the shield is installed, the drive is switched to standby mode.

  • Page 6: Pictorial View Of Installation

    Pictorial view of installation Technical data Supply voltage 230 V AC / Solar energy Drive type 24 V DC Drive power 150 W Maximum energy consumption (including zone lighting) 600 W Energy consumption in stand by mode 4,5 W Average number of working cycles daily 20 cycles daily Opening speed* 3 m / 16 s, beyond the deceleration area (20 cm)

  • Page 7: Preliminary Operations

    PRELIMINARY OPERATIONS Checks before installation ► Gate inspection The gate must be in good technical condition: check if its construction allows automation. The gate must be in a horizontal position during the whole displacement cycle; it must open and close without the necessity of using excessive power.

  • Page 8: Preliminary Wiring System

    EN 60335-1). It is recommended to install a lightning rod (maximum residual voltage 2 kV). ►Photocells (an option in Simple Move 101 set) Photocells are necessary for operation in automatic mode and to open a gate. • Photocell conductors (see page 23).

  • Page 9: Preparation Of The Foundations

    1. PREPARATION OF FOUNDATION Successive stages • Drive Unit location • Installation of stops • Foundations ►Drive unit location Horizontal setting Pay attention to the fact that that the drive unit must be always within the area of the gate operation, during both opening and closing.

  • Page 10: Mounting

    2. FASTENING Successive stages • Screw assembly • Drive fastening • Toothed bar assembly • Mechanical adjustment ►Screw assembly [1]. Place the assembly template on the ground (the template is printed on cardboard) and drill holes using a drill (Ø 12 mm) suitable for the ground type.
  • Page 11 ►Tooth bar assembly [1]. Check if the drive is really unlocked when the lever is in position 11 - [2]. Preparation of bars. No. 1 No. 2 No. 3 No. 4 [3]. Assembly of the bars should start from the lock side. [4].
  • Page 13 Fasten the first bar in such a way as to feel slight resistance. [6]. Level the bar. The bars No. 1 – No. 4 have bean-shaped elements for horizontal adjustment; The toothed bars can be adjusted vertically. Bean-shaped element Bean-shaped for vertical adjustment element for horizontal...

  • Page 14: Electrical Connections

    3. ELECTRICAL CONNECTIONS Successive stages • Connection of the drive unit • Connection to power supply • Connection to a solar energy source • Connection of safety accessories ►Connection of the drive Always connect the drive unit and the electronic module before the electronic module is connected to the mains.
  • Page 15 (See pages 23 and 24) The photocells must be fixed and connected before the start-up of the drive unit. The orange light (to be sold separately as an option in the set Simple Move 101) (See pages 26 and 27)

  • Page 16: Quick Start-Up

    4. QUICK START-UP Successive stages • Introduction to the remote control • Placing the label on the electronic module • Power up the system Push-button 1 • Gate track teaching ►Introduction to the remote controls The remote controls delivered in the set have been already programmed. Push-button 1 of the remote control allows the complete opening of the gate.

  • Page 17: Fitting The Shields

    5. SHIELD ASSEMBLY Check if the drive unit is locked. [1]. Place the shield on the flange (base) of the drive. [2]. Mount the gasket (6) to ensure the tight fitting of the drive unit and then the shield screw (5). THE DRIVE UNIT IS READY FOR ACTION.

  • Page 18: Operational Use

    OPERATIONAL USE Operation in sequential mode Successive pressing of the same push-button on the remote control results in the following drive unit operation: Opening, Stop, Closing, Stop, Opening, etc. ►Complete opening Complete opening of the gate by pressing push-button 1. Stop the gate movement by renewed pressing of push-button 1.

  • Page 19: Operation In Automatic Mode

    For automatic operation, installation of the photocell set is necessary according to EN 12 453 (see description and information on conductors on pages 22 and 23). Polargos recommends installation of the orange light (see description and information on conductors on pages 26 and 27) and the zone lighting (see information on conductors on page 27).

  • Page 20: Operation Of Remote Controls Or Transmitters With 3 Push-Buttons

    Operation of remote controls or transmitters with 3 push-buttons Opening by pressing the „Up” Stopping by pressing the Closing by pressing the push-button central push-button „Down” push-button Note: The remote controls or transmitters with 3 push-buttons do not allow opening the gate in pedestrian entry mode.

  • Page 21: Advanced Parameter Setting

    ADVANCED PARAMETER SETTING Note: You cannot set parameters when the gate is running. Any introduced parameter changes will be taken into account after the first opening of the gate. Available push-buttons in remote controls with 2 or 4 push-buttons Each remote control push-button can be Available combinations of push-buttons for complete programmed for control of complete gate opening.

  • Page 22: Activation Of The Function Of Opening For Pedestrian Entry

    Activation of the function of opening for pedestrian entry The function of opening for pedestrian entry can be activated using the push-button of the programmed remote control with 2 or 4 push-buttons (see ‘Available push-buttons in remote controls’, page 19). [1].

  • Page 23: Accessories

    ACCESSORIES A cross-section of conductors for individual types of devices concentric cable...
  • Page 24 Photocells------------------------------------------------ IP44 2 x 0.75 mm + 60°C Photocells cause the gate to stop and reverse direction during closing in the case of obstacle detection (photocells obstructed). 24 Vac/dc - 20°C HO5 RR-F Note: If the gate is closed and the photocells are obstructed, the 43 mm 26 mm gate will not open.
  • Page 25 1 2 3 5 1 2 3 5 1 2 1 2 3 5 Yellow label (BUS) 3 4 3 4 X X To check that the photocells are set properly, mount the shield of the transmitting photocell but do not install the shield of the receiving photocell. Check proper setting of the photocells: - If the receiving photocell indicator does not light up, adjust the position of the photocell...
  • Page 26 ► Recognition of photocells by the electronic system of the drive unit when in sequential mode [1]. Put the programmed remote control with 2 or 4 push- buttons on the picture showing a target. Press remote control push-button 1 until the AUTOMATIC CLOSING indicator goes out and then starts flashing.
  • Page 27 Orange light------------------------------------------------------- Ø22 The orange light indicates that the drive unit is running. + 60°C It starts flashing 2 seconds before the gate starts moving. - 20°C 24 V ► Installation of orange light 10 Watt max There are two methods available of installing the orange light (see Fig.
  • Page 28 ►Conductors of orange light Connect the orange light to the terminals 7 and 8 (orange label „FLASH”) of the electronic module. Zone lighting ----------------------------------------------------- This element is not compatible with a solar energy supply. Connect the zone lighting to terminals 13 and 14 (white label „LIGHT”) of the electronic module.
  • Page 29 ►Battery conductors and installation Connect the battery to the electronic module terminal provided for this purpose (grey label „BATT”). Key switch----------------------------------------------------- This element is not compatible with a solar energy supply. Connect the key switch to the electronic module terminals 3 and 4 (yellow label „BUS”).
  • Page 30 Panel with digital code-------------------------------------- This element is not compatible with a solar energy supply. – H P2 M P1 T3 C3 R3 T2 C2 R2 T1 C1 R1 V Connect: • T1 and C1 of the panel with a digital code to the electronic module terminals 3 and 4 (yellow label „BUS”). •...

  • Page 31: Solar Energy Supply

    SOLAR ENERGY SUPPLY Never connect the drive unit to a power supply of 230 V when it is already connected to a solar energy source because this can lead to damage to the electronic module of the drive. When the drive unit operates using a solar energy supply: - the gate can be controlled by means of remote controls and radio transmitters only (wire control is inactive), - protecting wire accessories (photocells, the orange light) are still active.

  • Page 32: Troubleshooting

    TROUBLESHOOTING Switch off the power supply of the system during cleaning or any other maintenance activities. DIAGNOSTICS FAULT CLEARING Limited operating range - Check the battery of the remote control (see The drive does not of the remote control. „Replacement of the remote control battery” on the respond to commands next page).
  • Page 33 DIAGNOSTICS FAULT CLEARING Thermal protection of the Wait for the drive to cool down until the STATUS 5 pulses drive is switched on. indicator starts emitting light continuously. Short circuit at the output Check the device connected to the output 24 V of the 6 pulses 24 V (terminals 5-6) of the electronic module.
  • Page 34 ►Antenna conductors and position The antenna must be connected to terminal 1 of the electronic system of the drive unit and positioned as shown in the picture on the right. ►Removal of settings The following settings can be removed: the gate path and activation of the automatic gate closing mode.
  • Page 35 ►Removal of programmed settings and remote controls The following settings can be removed: the gate path, activation of the automatic gate closing mode and all programmed remote controls or radio transmitters. [1]. Put the programmed remote control with 2 or 4 push-buttons on the picture showing a target. Press remote control push-button 1 until the AUTOMATIC CLOSING indicator starts flashing.
  • Page 36 Oziemkówka 57A 08-420 Miastków Kościelny, Polska Tel. 48 25 683 05 55, fax: +48 25 683 78 38 e-mail: serwis@polagros.pl www.polargos.eu...
