- Page 1 EASY WAY DRIVE UNIT FOR SWING GATES...
- Page 2 4 SETS M8 x 40 mm 2 SETS 8 SETS M6 x 40 mm M8 x 85 mm* *this lock screw is designed for gates mounted on steel posts 70 x 70 mm; if the gate is to be mounted on steel posts 100 x 100 mm, 8 sets of lock sc- rews M8 x 120 mm should be obtained.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction .................4 Safety principles ..............5 Product description ............6 Preparation for assembly ............8 Installation: 1. Automatic system installation ........12 2. Electrical connections ...........17 3. Parameter setting ............20 Operational use ..............26 Troubleshooting ..............28 Accessories ...............29 In the case of a solar energy supply ........35... -
Page 4: Introduction
Introduction POLARGOS is a Polish manufacturer of residential and industrial fence systems as well as other steel products that has been operating on the market since 1994. Due to their many years’ experience, as well as their production and marketing facilities, POLARGOS manufactures products for a large number of domestic and foreign customers. -
Page 5: Safety Principles
Householders are obliged to transport all unwanted electronic and electrical equipment to a special waste collection area for their disposal and recycling. POLARGOS hereby declares that this product conforms to the basic requirements and other relevant regula- tions of the Directive 1999/5/CE. The Declaration of Conformity is available at www.polargos.eu. This product is authorised for use in the European Union and Switzerland. -
Page 6: Product Description
Product description This product is designed for gates used at residential properties (description below). Technical data Type EASY WAY 201 Supply voltage 230 V AC / Solar system Drive type 24 V DC Driving power 40 W Maximum energy consumption 600 W (including gate zone lighting) Energy consumption in stand by mode... - Page 7 Product description Leaf dimensions and maximum weight Maximum opening angle (for standard hinges) EASY WAY 201 200 kg 2,00 m 2,00 m Width of each leaf should be between 1 m and ‘L’. Maximum opening angle (for hinges fastened to the post side) Dimensions (in mm) Opening limiter The motor stops automatically using its internal limiter.
-
Page 8: Preparation For Assembly
Preparation for assembly Checkpoints before installation Gate inspection The gate is in good technical condition: it opens and closes without use of force. The gate remains in a level position during the whole movement cycle. It opens inwards to the garden. Gate types –... - Page 9 Preparation for assembly Necessary tools 10,5...
- Page 10 Preparation for assembly Preliminary wiring system To install the gate drive, proceed as follows: ● Lay down a power supply of 230 V to one of the posts and as close to the drive unit as possible. ● Connect the post together using a cable 2 x 1 mm2 (not included in the delivery). Provide a shield Orange ICT Ø...
- Page 11 Preparation for assembly Preparation of connectors In case use the lock screws M8 x 85 mm included in the delivery. POST 70x70 POST 70x70 8 SETS M8 x 85 mm In case where the metallic posts have dimensions 100 x 100 mm, provide 8 sets of lock screws M8 x 120 mm.
-
Page 12: Automatic System Installation
Automatic system installation Preparation of the gate Level the gate leaves. Set position of the automatic system. Mandrel advanced ultimately Apply the prepared set to the previously leveled and closed gate. The automatic system cannot rub against the gate fittings. POST 100x100 POST 70x70... - Page 13 Automatic system installation Hold the connectors P and L using a clamp. Apply the automatic system to the gate and see which holes in the gate crossbar line up with the bean-shaped holes in the connector V1 (use two selected bean-shaped holes).
- Page 14 Automatic system installation Next, attach the connector to the post (with the gate closed). The post must be drilled with a drill bit 10.5 . 10,5 Screw the connector to the post.
- Page 15 Automatic system installation Put the automatic system onto the suitably attached connectors. Check the position of the connector on the gate once again and adjust it if necessary. Remove the automatic system. Choose one hole in the connector that does not interfere with a rail. In its position, drill the gate crossbar with a drill 6.5 .
- Page 16 Automatic system installation Assembly of the yoke fastening the leaf Fasten the unlocking element on the yoke fastening the leaf using the screw To use the unlocking element properly, follow the assembly direction as shown in the diagram. Do not mount the screw from below. Fix the yoke fastening the leaf on the driving mandrel.
-
Page 17: Electrical Connections
Electrical connections Stages: ● Location of the electrical box on the post. ● Fastening of the electrical box on the post. ● Connection of the two servomotors. ● Connection of the antenna. ● Connection to the mains or solar system. Location of the electric box on the post. -
Page 18: Electric Connections
Electric connections Connection of two servomotors. The servomotors must be connected to the electrical box before the box is connected to the mains. Servomotor M1 must be mounted on the post of the leaf that opens first and closes last. The servomotor M1 moves the right leaf that opens as the first one and closes as the last one Cables of servomotors:... - Page 19 Electric connections Connection of the antenna. To ensure optimum operation, it is recommended to introduce the antenna cable through a cable bush. Never cut the antenna cable. Connection to the mains or solar system PROG In the case of supply from a solar system, see page 35. AUTO ON/OFF For safety reasons, these operations must be carried out...
-
Page 20: Parameter Setting
Parameter setting Stages: ● Explanation of symbols. ● Programming the remote control. ● Leaf path teaching. ● Automatic mode adjustment. ● Switchover from automatic mode to sequential mode. ● Approval of settings. Explanation of symbols. Long pressing Indicator is flashing above 0.5 s Short pressing Indicator is lit... - Page 21 Parameter setting Programming of remote controls for complete opening only: Select a remote control push-button to be used for the gate control. Put the remote control in the place indicated on the housing: 1 Press the programming push-button and hold it down until the indicator PROG starts flashing PROG slowly (the indicator DANGER will be alight...
- Page 22 Parameter setting Deletion of remote controls 1. Press the reset pushbutton and hold it down for 7 seconds. > Four indicators emit light when the PROG indicators push-button is pressed. AUTO ON/OFF 2. Release the reset pushbutton. > Four indicators go out for 2 seconds. >...
- Page 23 Parameter setting Teaching of the movement path of leaves. The electronic system automatically programmes the following: The servomotor power necessary to control the gate in the usual mode. Saving of this information enables the detection of any anomalies in operation of the drive unit. Gate path in order to complete the opening and closing of the leaves as well as position of stops.
- Page 24 Parameter setting Checking of the correctness of settings 1. Press long the remote control push-button. 2. Press the push-button once again to stop the 2 leaves midway. 3. Disconnect the power supply for at least 5 seconds. 4. Reconnect the power supply. 5.
- Page 25 Parameter setting 3. Activate opening (from the usual distance) using the remote control. > The gate opens at nominal speed. 4. Once the gate is open completely: - Wait for the required period of time. - Activate closing by (shorter or longer) pressing the remote control push-button again.
-
Page 26: Operational Use
Operational use Operation in sequential mode Operation of complete opening mode ● Press the remote control push-button long. > Both leaves should open. Repeated (shorter or longer) pressing results in the closing of leaves. Operation of opening mode for pedestrian entry (if programmed) ●... - Page 27 Operational use Operation of lighting Zone lighting is turned on every time the drive is activated. The light goes out automatically two min- utes after the gate movement is finished (if the system is supplied from the mains) or 30 seconds (if the system is supplied from the solar energy source).
-
Page 28: Troubleshooting
Troubleshooting EASY WAY 201 is not responsible for the working of the remote control The indicator ON/OFF does not light up after the power supply is connected. Check the mains. Check the supply cable. Check the fuse. The indicator DANGER emits light continuously. This signal indicates photocell failure. Check the photocell setting. -
Page 29: Accessories
Accessories – Description and connections Photocells Photocells cause the gates to stop or reverse their motion in the case of obstacle detection. Installing a set of photocells is possible. Each photocell set consists of: ● A transmitting photocell (TX), ● A receiving photocell (RX). max. - Page 30 Accessories – Description and connections Emergency battery Accessories incompatible with solar energy supply. The emergency battery ensure the gate operation at low speed in the case of electrical failure. The battery is built in the electronic module of the drive unit and connected to it directly. PROG AUTO ON/OFF...
- Page 31 Accessories – Description and connections Key switch Intercom Accessories incompatible with solar energy supply.
- Page 32 Accessories – Description and connections Cable panel with code Accessories incompatible with solar energy supply. – H P2 M P1 T3 C3 R3 T2 C2 R2 T1 C1 R1 V – H P2 M P1 T3 C3 R3 T2 C2 R2 T1 C1 R1 V...
- Page 33 Accessories – Description and connections Wireless wall switch Radio panel with code Remote control with 2 push-butt Remote control with 4 push-buttons...
- Page 34 Accessories – Description and connections External antenna An external antenna having a wider range can replace the wire antenna. Place it on top of the post and check if it is exposed. Connection to the electronic module: conductor core to terminal 1, stranded aerial wire to the terminal 2. max.
-
Page 35: In The Case Of A Solar Energy Supply
In the case of a solar energy supply Parameter setting, programming and the drive unit operation remain the same as for a power supply of 230 V. Connection to a solar system supply Solar collector PROG AUTO ON/OFF 1. Insert the cable into the gland PROG of the electric box of the drive unit. - Page 36 Accessories: Photocells Wiring diagram for the photocell set 1 2 3 5 Lamp for gate zone illumination 24V - 25W...
