Connections; Back Panel Controls And Connections - Audio Research Reference 750 SE Manual

XLR input
A.C. Mains connector

Connections

Back Panel Controls and Connections

INPUT
PUSH
200K BAL
HOUR METER
RESET
REFERENCE 750
MONAURAL AMPLIFIER
PLYMOUTH, MINNESOTA
MADE IN U.S.A.
WARNING
TO PREVENT FIRE AND SHOCK HAZARD, DO NOT
EXPOSE THIS DEVICE TO RAIN OR MOISTURE.
UNIT MUST BE OPERATED IN A HORIZONTAL POSITION.
-DO NOT OPERATE WITH COVERS REMOVED-
UNIT CONTAINS VOLTAGES WHICH MAY BE HAZARDOUS.
CAUTION
FOR CONTINUED PROTECTION AGAINST
FIRE HAZARD REPLACE FUSE ONLY
WITH SAME TYPE AND RATING
SERIAL
VOLTS
~
2200W MAX 20A FUSE
50/60 HZ SLO-BLO
10A (240V)
Fuse holder
8
WARNING
RISK OF HAZARDOUS ENERGY!
MAKE PROPER SPEAKER CONNECTIONS
SEE OWNERS MANUAL.
+ + +
4 8 16
4 8 16
- - -
Speaker connections
hour meter
