3. Operating Principles

3.1. How the scooter works
The scooter uses digital electronic gyroscopes and acceleration sensors to control balance and motion intelligently, depending on the user's center of gravity. The device
also uses an intelligent control system to drive the brushless motors that are located within the wheels. The scooter has a built-in inertia dynamic stabilization system that
can help assist with balance when moving forward and backwards, but not while turning.
TIP -To increase your stability, you must shift your weight in order to overcome the centrifugal force during turns, especially when entering a turn at higher speeds.
3.2. PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY
Step 1: Getting Started - Take your scooter out of the box and place it at on the oor.
Press and hold the power button, located on the front of your scooter, next
to the 3-pin charging port.
Power button
Step 2: Checking the Display Board - located in the center of your scooter. The scooter
should power on and beep indicating it is on. The Battery indicator light should
be lit, indicating there is power to the device.
Battery Indicator
A. Battery Indicator: The solid LED light indicates the scooter is charged
and when the remaining battery is down to 10% a buzzer will alarm telling
you to recharge the device.
B. Running Indicator: When the operator triggers the rubber foot mats, the
Running Indicator LED will light up, which means that the system enters the
running state; when the system has an error during operation, the running
LED light will turn red and you will hear the system alert you with a beep.
Step 3: Charging your Scooter - Make sure the scooter is fully charged before your
initial use. For charging instructions, please follow details in Section 8 under
Battery and Charging Speci cations.
Step 4: Safety Gear - Wear all proper safety gear, including, but not limited to a helmet,
knee pads, elbow pads, and wrist guards.
3-pin Charging Port
Running Indicator
Helmet
Elbow Pads
Wrist Guards
Knee Pads
