Celestron Mossy Oak Gamekeeper FireCel+ 93549 Quick Start Manual

Model # 93549
Thank you for purchasing the Mossy Oak/Gamekeeper FireCel+,
a Rechargeable Power Pack, Hand Warmer & LED Flashlight!
The FireCel+ is an essential multi-use tool designed to
be used in the elements. Its hand warmer feature provides
long lasting heat, while its portable, high-capacity power
pack can supply power to your smartphone, MP3 player,
and many other USB-powered devices. A built-in flashlight
provides illumination while the hand warmer keeps you comfortable
in cold conditions.
WARNING: Read all instructions and warnings thoroughly before
using. Improper use of this product may result
in product damage, excess heat, toxic fumes,
fire or explosion. Do not allow children to use this
product without proper adult supervision.
INCLUDED IN THE BOX ARE:
1 - FireCel+ Rechargeable Power Pack, Hand Warmer
& LED Flashlight
1 - USB Cable with Mini USB connection
1 - Carrying strap
1 - Soft carrying bag
PARTS CALLOUT
1
2
3
4
5
7
1. Four super bright LEDs (two red, two white)
2. Six indicator lights
• Four blue LEDs display battery level
• One green LED indicates a device is being charged
• One red LED indicates heat mode is in use
3. Flashlight on/off button
4. Multi-function button
5. Aluminum heating element
6. Mini USB IN port
7. USB 2.0 OUT port
1. CHARGING THE INTERNAL LITHIUM
ION BATTERY
Your FireCel+ has an internal, 5200 mAh rechargeable lithium ion
battery, which allows for up to 12 hours of continuous heat when
using the hand warmer at a constant temperature of 45° to 50°
Celsius (113° to 122° Fahrenheit). The FireCel+ also charges
multiple USB-powered devices, and is equipped with a red and
white LED flashlight.
Your FireCel+ ships with a partial charge, but you should charge it
completely before using for the first time.
Follow these steps to charge the internal lithium ion battery:
1. Using the supplied USB cable, plug the Mini USB plug into the
Mini USB port (#6) on your FireCel+.
2. Plug the standard USB plug end of the included USB cable into
a USB port on a PC, laptop, car charger or USB 5V-500mA
adapter plug.
3. Once plugged in, the four blue LEDs (2) will start to blink,
indicating that charging is in progress.
4. Charging is complete when all four blue LEDs (2) stop blinking.
NOTE: FireCel+ is designed with overcharge protection to prevent
damage to the internal battery.
2. USING THE HAND WARMER FEATURE
• First, press and release the multi-function button (4) to check
the power level. The blue indicator lights will display the current
battery level. (The number of illuminated LEDs corresponds to the
charge level: (1) 25%, (2) 50%, (3) 75%, (4) 100%).
• Press the multi-function button (4) again to activate one side of
the hand warmer. The green and red indicators will illuminate. In
this mode, you can also charge an external device. See section
3 below.
• Press the multi-function button (4) again to activate both sides of
the hand warmer. Only the red LED indicator will illuminate. You
cannot charge an external device in this mode.
7
• Press the multi-function button (4) one more time to turn off the
hand warmer.
3. CHARGING AN EXTERNAL DEVICE
6
• First, press and release the multi-function button (4) to check
the power level. The blue indicator lights will display the current
battery level. (The number of illuminated LEDs corresponds to the
charge level: (1) 25%, (2) 50%, (3) 75%, (4) 100%).
• Plug your device's USB charging cable into the USB 2.0 port (7).
• Press and release the multi-function button (4) again. The green
indicator light will illuminate and your device should indicate it
is charging.
• When charge is complete, the FireCel+ will automatically
power off. To manually stop the charging process, remove
the charging cable.
4. USING THE FLASHLIGHT FEATURE
• Press the flashlight on/off button (3) to turn on flashlight mode
1 (red LEDs only). Continuing to press the flashlight ON/OFF
button (3) will advance through the modes in this order:
1. Red LEDs only
2. White LEDs only
3. Red LEDs blinking
4. White LEDs blinking
5. Red and White LEDs SOS
6. OFF

5. SPECIFICATIONS

BATTERY: 5200mAH/3.7V Rechargeable Lithium Ion
(2 x 2600 mAh)
INPUT VOLTAGE: 5V- 500 mA to 2A
(Smart Charge Technology)
OUTPUT VOLTAGE: 5V- 1A
PORTS: (1) MINI USB (for charging internal battery)
(1) STANDARD USB 2.0 (for charging external devices)
INTERNAL BATTERY CHARGE TIME
Power supply USB-PC/CC 500mA:
Power supply 5v/1A/CC 900 mAh:
Power supply 5V/2A/CC 1.8A:
MINIMUM NUMBER OF RECHARGES > 500
LED STATUS INDICATORS
(4) Blue LEDs indicate internal battery status
(1) Red LED indicates hand warmer mode
(1) Green LED indicates charging external device
HAND WARMER TEMPERATURE RANGE
45° TO 50° Celsius (113° TO 122° Fahrenheit)
HAND WARMER CONTINUOUS USE TIME
Single Side Mode: 12 hours continuous use
Dual Side Mode: 6 hours continuous use
(Based on fully charged battery)
FLASHLIGHT MODES:
1. Red LEDs only
2. White LEDs only
3. Red White Flashing
4. Emergency SOS
OPERATING TEMPERATURE RANGE:
0° to 45° Celsius (32° to 113° Fahrenheit)
S
TORAGE TEMPERATURE RANGE:
68° to 77° Fahrenheit (optimal)
POWER DELIVERY CHART
iPhone 5s (1540 mAh): 2 hours (2.5 times)
iPhone 4s (1400 mAh): 1.8 hours (2.7 times)
iPhone 3GS/iPod (1200 mAh): 1.5 hours (3.2 times)
HTC WILDFIRE: 1.6 hours (3 times)
WEIGHT: 3.52 oz. (148 grams)
DIMENSIONS: 2.58 in x 3.49 in x .96 in
(65.5 mm x 88.6 mm x 24.5 mm
11.0 hours
6.5 hours
3.6 hours
)
