Velopex Intra-X User Manual page 10

Daylight Loader Installation (cont.)
(Back of
Loader)
(Front of
Loader)
3b.
4.
(Retaining
Screw X 2)
5.
VELOPEX INTRA-X
WARNING:
When Removing
the Fixer and Developer modules, slide
tanks sideways until completely clear of
the immersion heaters mounted on the
machine internal wall.
Unscrew the Two Retaining
Screws and Remove White
protective strip from sealing
material on the back of the
loader.
Remove Protective Film from
Viewing Window Cover.
6
User Guide
