Velopex Intra-X User Manual

Automatic x-ray film processor
Hide thumbs Also See for Intra-X:
Table of Contents

Advertisement

Quick Links

Intra - X
Intra - XE
Automatic X-Ray Film Processor
USER GUIDE
Operation and
Maintenance manual
WARNING:
Do not plug into the electrical mains power supply before
reading this manual – or before filling the machine with
liquids
Register your machine by returning the Warranty Card
to enable full customer support.
Machine serial number to be
quoted on all correspondence:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Intra-X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Velopex Intra-X

Summary of Contents for Velopex Intra-X

  • Page 1 Automatic X-Ray Film Processor Intra - X Intra - XE USER GUIDE Operation and Maintenance manual WARNING: Do not plug into the electrical mains power supply before reading this manual – or before filling the machine with liquids Register your machine by returning the Warranty Card to enable full customer support.
  • Page 2 This will ensure a long life for your processor. This manual is to be used with the following Velopex processors: Intra-X, Intra-XE. Warranty may be voided if the processor is incorrectly installed or maintained outside the guidelines set forth in this manual.
  • Page 3 Velopex Processor - Exterior Velopex X-Ray Film Processor - Left Side Film Collector Viewer Cover Endo Slide Daylight Loader viewing Window Transport Module On/Off Power Switch Hand entry port/Glove ‘Run’ Button Daylight Loader - Left Side Film Entry Guide Machine Accessories and Extras Supplied...
  • Page 4 VELOPEX INTRA-X User Guide Table of Symbols Symbol Description Alternating Current Off (Power: Disconnect from the mains) On (Power: Connect to the mains) Type ‘b’ equipment ‘RUN’ Button / Process switch Protective Earth (Ground) Symbols used within Manual Attention / Warning...

  • Page 5: Table Of Contents

    Contents Specification ..............Installation* ........................ 3 Pre Installation Instructions ..5 Daylight Loader Installation (when required) .............. 8 Filling with Chemicals Operation ..............11 Maintenance ..............15 Trouble Shooting ............19 Service Log ..............24 © June 2005 Medivance Instruments Limited All rights reserved.

  • Page 6: Specification

    VELOPEX INTRA-X User Guide Specification Width (W) 290mm / 11½” Depth (D) 435mm / 17” Inc. Loader 635mm / 25” Height (H) 315mm / 12½” Weight: Empty 12.1Kg / 26½lb Full Tanks 13.9Kg / 30½lb Tank Capacity 1.4litres / 2½Imp Pints each...

  • Page 7: Installation

    VELOPEX INTRA-X User Guide Pre Installation Instructions • Unpacking the VELOPEX NOTE: For unpacking and lifting the machine into position it is important to have assistance. The machine comes in a single carton containing: Machine, Operator’s Manual, Silicone Grease, Electrical Cord, Transport Module Turning Tool, Cleaning Brush, Chemical Change Chart and a box of Cleaning Tablets (UK only), and Daylight Loader (as required).
  • Page 8 VELOPEX INTRA-X User Guide Pre Installation Instructions (cont.) • Siting of the VELOPEX When using the machine in daylight or a darkroom, avoid sources of intense light. Do not mount the unit under a window, fluorescent light or flood lamp.

  • Page 9: Daylight Loader Installation (When Required)

    VELOPEX INTRA-X User Guide Daylight Loader Installation (as required) Bring the Lid to the upright position. TIP: The Lid can be kept in the upright position while the machine is open, or lifted away. Remove Side Panel by Sliding it Upwards in its Runners.
  • Page 10 VELOPEX INTRA-X User Guide Daylight Loader Installation (cont.) WARNING: When Removing the Fixer and Developer modules, slide tanks sideways until completely clear of the immersion heaters mounted on the machine internal wall. Unscrew the Two Retaining Screws and Remove White...
  • Page 11 VELOPEX INTRA-X User Guide Daylight Loader Installation (cont.) Slide Loader over Film Entry Guide and ‘RUN’ Button, Press the Loader firmly against Ma- chine. Secure Loader with the Two Retaining Screws.

  • Page 12: Filling With Chemicals

    ½ Pouring in 1 quarts (1400ml) of fluid. TIP: Use VELOPEX chemicals designed for your unit. If unobtainable use ONLY another proprietary chemical & always read and follow instructions on bottle. WARNING: DO NOT use Chemistry or Film designed for manual...
  • Page 13 VELOPEX INTRA-X User Guide Filling with Chemicals (cont.) Fill the tanks up to the lowest edge of the Sight Glass. Lower Transport Modules carefully into their respective tanks. Top up - the correct liquid level will show half way up the sight glass.
  • Page 14 VELOPEX INTRA-X User Guide Filling with Chemicals (cont.) (Drive Pin & Drive Dog) To avoid spillage, carefully return tanks to the machine. Start with the Developer tank followed by the Fixer, Water and finally the Dryer tanks. Engage the module drive pins into the drive dogs, working from right to left.

  • Page 15: Operation

    TIP: Intra-XE has no heating and therefore no temperature indicator. It relies on ambient room temperature of - 25 The Velopex is equipped with automatic stand-by mode. To initiate processing press the ‘RUN’ Button. TIP: From time to time the...
  • Page 16 VELOPEX INTRA-X User Guide Operating the Processor (cont.) Put Hands through Loading Ports and place Film inside Daylight Loader. WARNING: Always remove old film wrappers from inside the loader. (Image for instruction ONLY, Viewing Window is closed when operating machine) Press ‘RUN’...
  • Page 17 Remove film from ENDO slot. TIP: After film exits, you can view and then wash it with water and hang it up to dry. WARNING: Make sure film does not fall back into the Velopex - remove it as soon as it emerges.
  • Page 18 VELOPEX INTRA-X User Guide Operating the Processor (cont.) Film Feeding direction. TIP: Centre the film on the guide provided to post the film through the processor. WARNING: Make sure the film is fed in squarely, and in the centre of the entry slot, short edge leading.

  • Page 19: Maintenance

    VELOPEX INTRA-X User Guide Velopex Processor Cleaning Quality Assurance - for instructions refer to back of VISCHECk Quality Manager board supplied with your machine. TIP: Regular use of this product will ensure the quality of the film processing and reduce the risk of retakes.
  • Page 20 VELOPEX INTRA-X User Guide Velopex Processor Cleaning (cont.) Module cleaning - Immerse the Modules in a tank/sink filled with hot water and scrub with the supplied brush around the gears and roller ends. TIP: Use the turning tool; turn the gears and belts by hand to assist in thorough cleaning.
  • Page 21 VELOPEX INTRA-X User Guide Velopex Processor Cleaning (cont.) Add Velopex Cleaning Tablets one per tank.. Replace Modules and run for TWO cycles at operating temperature. Dryer Module Cleaning - Place Dryer Module in container or sink filled with fresh cold water.
  • Page 22 Fill up with Chemicals (See Installation sections 10-12, pages 6-7). For best results, use VELOPEX chemicals. TIP: Use the chart provided and keep a note of the date when chemicals were changed.

  • Page 23: Trouble Shooting

    VELOPEX INTRA-X User Guide...
  • Page 24 VELOPEX INTRA-X User Guide...
  • Page 25 VELOPEX INTRA-X User Guide...
  • Page 26 VELOPEX INTRA-X User Guide...
  • Page 27 VELOPEX INTRA-X User Guide...

  • Page 28: Service Log

    VELOPEX INTRA-X User Guide Service Log: Date Service Description Serviced By Machine Installation MC = Monthly Cleaning ; WIA = When In Area ; SC = Service Call Service Log Table Use this table to record any service/maintenance done, including: Installation, Engineer- Servicing, Parts replaced by user, etc.
