EdenPURE CordFree Vac Instruction Manual
EdenPURE CordFree Vac Instruction Manual

EdenPURE CordFree Vac Instruction Manual

High performance cordless handheld vacuum cleaner

Advertisement

Quick Links

EdenPURE
High performance cordless handheld Vacuum Cleaner
®
Instruction Manual
CordFree Vac
IMPORTANT
SAVE THESE
INSTRUCTIONS
To ensure you get the best results from your CordFree
Vac, please read this manual first and keep it for future
reference. For additional information, please contact
your place of purchase or call
Thank you for choosing EdenPURE ®
1-800-225-6595

Advertisement

loading
Need help?

Need help?

Do you have a question about the CordFree Vac and is the answer not in the manual?

Questions and answers

Summary of Contents for EdenPURE CordFree Vac

  • Page 1 To ensure you get the best results from your CordFree Vac, please read this manual first and keep it for future reference. For additional information, please contact 1-800-225-6595 your place of purchase or call Thank you for choosing EdenPURE ®...
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE. RETAIN INSTRUCTIONS FOR FUTURE REFERRENCE. Do not use in rain or leave outdoors when it's raining WARNING: Basic safety precautions should always be observed when using an electrical appliance, including the following to reduce the risk of fire, electrical shock, or injury.
  • Page 3 6. Do not abuse the charger cord. 7. Never carry the charger by the cord. 8. Do not pull the cord to disconnect from a socket, grasp the plug and pull to disconnect. 9. Don’t wrap the cord around the charger when storing. 10.
  • Page 4 Service: 1. Before using the appliance and after any impact, check for signs of wear or damage and repair as necessary; 2. Do not use the appliance if any part is damaged or defective. 3. Repairs should be carried out by a service agent or a suitably qualified person in accordance with relevant safety regulations.
  • Page 5: Introduction Of Components

    Introduction of components: Switch Metal tube lock Long crevice Dust cup 2 in 1 crevice Metal tube Charger base Power brush locker Power brush Charger Round brush Flexible hose Up side brush I. Use as a stick vacuum cleaner Assemble the dust cup in counter-clockwise direction.
  • Page 6 Attach the metal tube to the body as shown below until you hear a clicking sound. Switch/Speed control Attach the brush to the other end of metal tube A. Low power as shown below. Push the button once for low power. B. High power Push the button a second time for high power. Push the button a third time to turn the unit off. Press the switch to start. II.
  • Page 7 Using the flexible hose Insert the flexible hose into the main unit and connect the accessories to the other end of the flexible hose. Using the top side brush...
  • Page 8 Charging the battery When the battery power indicator is blinking red, please power off then put back on charge base for charging (as shown on the right). Battery indicator How to empty the dust cup 1. Press the metal tube lock then 2. Unlock the dust cup lock take out the metal tube 3. Empty the dust cup...
  • Page 9 How to maintain the filter 1. Press the dust cup lock and turn it in a clockwise direction. 2. Take out the filter case, then remove the filter. 3. Wash the filter case and HEPA filter. 4. Please dry the HEPA filter and filter case 5.
  • Page 10: Technical Specification

    Power 160W Vacuum 14Kpa Airflow 15 dm3/s WARNING ANY REQUIRED SERVICE OTHER THAN FILTER MAINTENANCE SHOULD ONLY BE PERFORMED BY AN AUTHORIZED SERVICE REPRESENTATIVE SERVICE – For repairs or service, please call 1-800-225-6595 or visit www.edenpuresupport.com . ©2019 EdenPURE® I-5583 BR11824R-1...
