AQ5311D
AQ5311D BK
USER MANUAL
TABLE OF CONTENTS
FOR YOUR SAFETY .............................................................................. 1
SAFETY PRECAUTIONS ................................................................. 1
SPECIAL NOTES ON LCD MONITORS ............................................. 3
CUSTOMER SERVICE ...................................................................... 3
CLEANING ....................................................................................... 3
BEFORE YOU OPERATE THE MONITOR ................................................ 4
FEATURES ....................................................................................... 4
CHECKING THE CONTENTS OF THE PACKAGE ............................. 4
CONTROLS AND CONNECTORS .................................................... 5
CONNECTING YOUR MONITOR ...................................................... 6
COMPUTER SETTING ....................................................................... 8
ADJUSTING THE HEIGHT AND THE VIEWING ANGLE .................... 9
PANEL ROTATION ............................................................................ 9
OPERATING THE MONITOR ................................................................... 10
ADJUSTMENT MENU CONTENTS .................................................... 11
SCREEN ADJUSTMENTS ................................................................. 14
POWER MANAGEMENT FEATURE .................................................. 17
TROUBLE SHOOTING ............................................................................ 18
APPENDIX .............................................................................................. 19
SPECIFICATIONS ............................................................................. 19
COMPLIANT TIMING ......................................................................... 20
CONNECTOR PIN ASSIGNMENT ...................................................... 21
Thank you very much for choosing the iiyama LCD monitor.
We recommend that you take a few minutes to read carefully through this brief but
comprehensive manual before installing and switching on the monitor. Please keep this
manual in a safe place for your future reference.
All manuals and user guides at all-guides.com
ENGLISH
DEUTSCH
FRANCAIS
NEDERLANDS
SVENSKA
ITALIANO
Advertisement
Table of Contents
Related Manuals for Iiyama AQ5311D
Summary of Contents for Iiyama AQ5311D
-
Page 1: Table Of Contents
COMPLIANT TIMING ................. 20 CONNECTOR PIN ASSIGNMENT ............21 Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this... - Page 2 To meet the FCC requirements, you should use a signal cable with ferrite core at both ends. CAUTION Changes or modifications not expressly approved by iiyama could void the users authority to operate the device under FCC compliance regulations. CANADIAN DEPARTMENT OF COMMUNICATIONS COMPLIANCE...
-
Page 3: For Your Safety
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fire or electric shock. - Page 4 All manuals and user guides at all-guides.com CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor.
-
Page 5: Special Notes On Lcd Monitors
Power Switch for hours. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, flickering or not lighting up. Never attempt to replace it by yourself. -
Page 6: Before You Operate The Monitor
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office. n Power Cable*... -
Page 7: Controls And Connectors
All manuals and user guides at all-guides.com CONTROLS AND CONNECTORS < Front > < Back > A Power Indicator Green: Normal operation NOTE Orange: Power Management The monitor enters into power management mode which reduces the power consumption to less than 13.5W when receiving no horizontal and/or vertical sync signal. -
Page 8: Connecting Your Monitor
The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. n For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama office for a suitable adaptor. - Page 9 All manuals and user guides at all-guides.com [Cable Wiring] A Collect cables at the back of the stand. B Place the Cable Cover by inserting the tabs into guide holes and then sliding the cover downward. [AC Adapter Installation] Screw (Accessory) A Attach the AC Adapter Holder to the AC Adapter.
-
Page 10: Computer Setting
VGA. n Windows 95/98/2000/Me/XP Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows 95/98/2000/Me/XP by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied. -
Page 11: Adjusting The Height And The Viewing Angle
All manuals and user guides at all-guides.com ADJUSTING THE HEIGHT AND THE VIEWING ANGLE n For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s height and angle to your own preference. n Hold the panel so that the monitor does not topple when you change the monitor’s height or angle. -
Page 12: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 20. You are also able to adjust the picture by following the button operation shown below. -
Page 13: Adjustment Menu Contents
All manuals and user guides at all-guides.com ADJUSTMENT MENU CONTENTS Direct You can skip the Menu display and perform an adjustment immediately by using the following button operations. l Brightness: Press the Brightness Button when the Menu is not displayed. l Contrast: Press the Contrast Button when the Menu is not displayed. - Page 14 All manuals and user guides at all-guides.com Adjustment Item Problem / Option Button to Press Too far to the left H-POSITION Too far to the right Too low V-POSITION Too high NORMAL The picture is displayed at the optimum resolution. IMAGE SIZE * EXPANDED Stretch the picture to fit the full screen.
- Page 15 All manuals and user guides at all-guides.com DVI-Digital Input Adjustment Item Problem / Option Button to Press Too dark BRIGHTNESS * Direct Too bright Too dull CONTRAST Direct Too intense PRESET1 9300K COLOR 6500K PRESET2 PRESET3 5500K USER Too weak MODE GREEN Too strong...
-
Page 16: Screen Adjustments
If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Automatic set-up, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the iiyama web site (http://www.iiyama.com or http:/ /www.iiyama.co.uk). - Page 17 All manuals and user guides at all-guides.com C Select AUTO in IMAGE SET-UP and perform the Automatic set-up. Or press the Buttons at the same time when the Menu is not displayed. (Direct adjustment) D Adjust the image manually by following procedure below when the screen has a flicker or blur, or the picture does not fit in the display area after performing the Automatic set-up.
- Page 18 All manuals and user guides at all-guides.com G Adjust the FINE in IMAGE SET-UP to correct horizontal wavy noise, flicker or blur in the zebra pattern. n In case the strong flicker or blurs remain on a part of the screen, repeat steps F and G NOTE because the COARSE may not be adjusted correctly.
-
Page 19: Power Management Feature
All manuals and user guides at all-guides.com POWER MANAGEMENT FEATURE The power management feature of this product automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a power management step the monitor takes as described below. -
Page 20: Trouble Shooting
MONITOR or if the problem persists. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem Check The picture does not appear. -
Page 21: Appendix
All manuals and user guides at all-guides.com APPENDIX SPECIFICATIONS Driving system Panel Size Diagonal: 52.8cm / 20.8" Pixel pitch 0.207mm H × 0.207mm V Brightness 235cd/m (Typical) Contrast ratio 300 : 1 (Typical) Viewable angle Right / Left / Up / Down: 85 degrees each (Typical) Response time 50ms typical, 68ms maximum (Black, white, black) Display Colors... -
Page 22: Compliant Timing
All manuals and user guides at all-guides.com 472mm/18.6" 87mm/3.4" 425.4mm/16.7" 344mm/13.5" ( ): Maximum adjustment range COMPLIANT TIMING Horizontal Vertical Dot Clock Video Mode Frequency Frequency 640 × 350* 31.47kHz 70.00Hz 25.17MHz 640 × 480 31.47kHz 60.00Hz 25.18MHz 720 × 400* 31.47kHz 70.08Hz 28.32MHz... -
Page 23: Connector Pin Assignment
All manuals and user guides at all-guides.com CONNECTOR PIN ASSIGNMENT n D-Sub mini 15pin Connector Input Signal Input Signal Red video Green video Ground Blue video Ground Ground Data line (SDA)* Ground H-Sync / HV-Sync Red video ground V-Sync Green video ground Clock line (SCL)* Blue video ground * Compliant to VESA DDC.
