Microphone Base for PC compatible with ADAM Software
Products for VoIP SIP LAN networking Communications, Paging Amplifiers Systems and
Audio Applications. Zone Announcements, Night Ringer, Multicast general call,
Background music, Standard SIP call or Emergency call, SD memory with pre-recorded
messages, Relays for LAN drives.
Revision
Date
0
01/03/2018
TEMA TELECOMUNICAZIONI
"IP COMMUNICATION AND SECURITY COMPANY"
WWW.TEMATLC.IT
AD696/AA
Serie Audio Over IP Network
PRODUCT MANUAL
Version HW 1.0
Revision reason
First release
Prepared
DP
Checked/Approved
DP, FL
Advertisement
Table of Contents
Related Manuals for Tema Telecomunicazioni AD696/AA
Summary of Contents for Tema Telecomunicazioni AD696/AA
- Page 1 TEMA TELECOMUNICAZIONI “IP COMMUNICATION AND SECURITY COMPANY” WWW.TEMATLC.IT AD696/AA Microphone Base for PC compatible with ADAM Software Serie Audio Over IP Network Products for VoIP SIP LAN networking Communications, Paging Amplifiers Systems and Audio Applications. Zone Announcements, Night Ringer, Multicast general call, Background music, Standard SIP call or Emergency call, SD memory with pre-recorded messages, Relays for LAN drives.
- Page 2 AD696/AA Microphone Base For PC TEMA TELECOMUNICAZIONI DICHIARAZIONE DI CONFORMITÀ CE DECLARATION OF CONFORMITY CE TEMA TELECOMUNICAZIONI SRL Via C. Girardengo, 1/4 - 20161 MILANO declare under our sole responsibility that the product: Base microfonica per annunci per PC Product name...
- Page 3 This document is property of Tema Telecomunicazioni, It is forbidden any duplication and reproduction, even partial, as well as storage on any medium without written permission of Tema Telecomunicazioni.
- Page 4 AD696/AA Microphone Base For PC TEMA TELECOMUNICAZIONI INDEX PAGE PRESENTATION ............................5 TECHNICAL SPECIFICATIONS ....................... 7 PACKING LIST ............................7 O PERATION............................... 8 CONNECTING THE MICROPHONE BASE TO THE PC................ 8 MAS-AD696-AA-REV00EN Page 4 of 8...
- Page 5 TEMA TELECOMUNICAZIONI 1. PRESENTATION The AD696/AA microphone base can be connected to a PC running the ADAM software for the centralized management of Tema IP audio devices. Through the AD696/AA microphone base enabled by the ADAM software, the announcements can be made on the LAN network in Multicast channels to the network amplifiers or to the AD600 series IP-SIP speakers of the SipComStage line.
- Page 6 AD696/AA Microphone Base For PC TEMA TELECOMUNICAZIONI VoIP SIP Amplifiers-Speakers Products and Accessories of the AD600 series “SipComStage” AD630 IP-SIP PoE 25W Horn Speaker AD330/xx Are available Speakers of with 40W internal amplifier (2x20W) IP65 different power, Horns and Loudspeakers protection.
-
Page 7: Technical Specifications
AD696/AA Microphone Base For PC TEMA TELECOMUNICAZIONI 2. TECHNICAL SPECIFICATIONS Microphone capsule Electret condenser Polar diagram Cardioid Frequency response 50 ÷ 16.000 Hz Output impedance 1000 Ohm Sensitivity -40dB (0dB 1V/Pa @1Khz) Controls Momentary PTT button, “ALWAYS-ON” switch Flexible gooseneck in 2 points... - Page 8 The operator who has the AD696/AA microphone base at his disposal, to issue an announcement on the speaker network after activating the "Microphone" function on the ADAM software window can: switch in "I" position On permanently enabled microphone (Recommended with ADAM software) •...
