- Page 1 TEMA TELECOMUNICAZIONI “IP COMMUNICATION AND SECURITY COMPANY” WWW.TEMATLC.IT AD696/A Paging Microphone Base for Announcements and Chime For Analog Amplifiers AD300 series PRODUCT MANUAL Version HW 1.0 Revision Date Revision reason Prepared Checked/Approved 09/04/2018 First release DP, FL...
-
Page 2: Dichiarazione Di Conformità Ce
AD696/A Paging Microphone Base for Announcements and chime TEMA TELECOMUNICAZIONI DICHIARAZIONE DI CONFORMITÀ CE DECLARATION OF CONFORMITY CE TEMA TELECOMUNICAZIONI SRL Via C. Girardengo, 1/4 - 20161 MILANO declare under our sole responsibility that the product: Base microfonica per annunci e din-don Product name... - Page 3 This document is property of Tema Telecomunicazioni, It is forbidden any duplication and reproduction, even partial, as well as storage on any medium without written permission of Tema Telecomunicazioni.
- Page 4 AD696/A Paging Microphone Base for Announcements and chime TEMA TELECOMUNICAZIONI INDEX PAGE PRESENTATION ..........................5 TECHNICAL SPECIFICATIONS ....................... 6 PARTI COSTITUENTI IL SISTEMA (PACKING LIST) ..............6 OPERATION ............................. 7 CONNECTION AND SUPPLY OF MICROPHONE BASE ..............8 MAS-AD696-A-REV00EN Page 4 of 8...
- Page 5 TEMA TELECOMUNICAZIONI 1. PRESENTATION The AD696/A Paging Microphone Base can be connected to an input of a Tema AD300 series analog power amplifier to launch announcements on the speaker network. The desktop base is equipped with a "Talk" switch to enable the microphone and a button to enable the emission of a chime sound before the announcement.
-
Page 6: Technical Specifications
AD696/A Paging Microphone Base for Announcements and chime TEMA TELECOMUNICAZIONI 2. TECHNICAL SPECIFICATIONS Microphone capsule Electret condenser Polar diagram Cardioid Frequency response 50 ÷ 16.000 Hz Output impedance 1000 Ohm Sensitivity -40dB (0dB 1V/Pa @1Khz) Controls 1 power on and “Talk” button, 1 “chime” button... -
Page 7: Operation
AD696/A Paging Microphone Base for Announcements and chime TEMA TELECOMUNICAZIONI 4. OPERATION Used together with the TEMA amplifiers of the AD300 series, the AD696/A microphone base allows an operator to transmit a message to a network of loudspeakers for alerts or announcements. Button for sending the "chime"... - Page 8 AD696/A Paging Microphone Base for Announcements and chime TEMA TELECOMUNICAZIONI 5. CONNECTION AND SUPPLY OF MICROPHONE BASE Open the door located under the base and insert two 1.5V AA batteries in the appropriate compartment respecting the correct insertion polarity, close the door.
