Paging Microphone Base for Announcements and Chime
Products for VoIP SIP LAN networking Communications, Paging Amplifiers Systems and
Audio Applications. Zone Announcements, Night Ringer, Multicast general call,
Background music, Standard SIP call or Emergency call, SD memory with pre-recorded
messages, Relays for LAN drives.
Revision
Date
0
20/03/2018
TEMA TELECOMUNICAZIONI
"IP COMMUNICATION AND SECURITY COMPANY"
WWW.TEMATLC.IT
AD696/BM
Serie Audio Over IP Network
PRODUCT MANUAL
Version HW 1.0 - Version SW 1.09m
Revision reason
First release
Prepared
DP
Checked/Approved
DP, FL
Advertisement
Table of Contents
Related Manuals for Tema Telecomunicazioni AD696/BM
Summary of Contents for Tema Telecomunicazioni AD696/BM
- Page 1 TEMA TELECOMUNICAZIONI “IP COMMUNICATION AND SECURITY COMPANY” WWW.TEMATLC.IT AD696/BM Paging Microphone Base for Announcements and Chime Serie Audio Over IP Network Products for VoIP SIP LAN networking Communications, Paging Amplifiers Systems and Audio Applications. Zone Announcements, Night Ringer, Multicast general call, Background music, Standard SIP call or Emergency call, SD memory with pre-recorded messages, Relays for LAN drives.
- Page 2 Paging Microphone Base for Announcements and Chime TEMA TELECOMUNICAZIONI DICHIARAZIONE DI CONFORMITÀ CE DECLARATION OF CONFORMITY CE TEMA TELECOMUNICAZIONI SRL Via C. Girardengo, 1/4 - 20161 MILANO declare under our sole responsibility that the product: Base microfonica per annunci e din-don Product name...
- Page 3 This document is property of Tema Telecomunicazioni, It is forbidden any duplication and reproduction, even partial, as well as storage on any medium without written permission of Tema Telecomunicazioni.
- Page 4 Paging Microphone Base for Announcements and Chime TEMA TELECOMUNICAZIONI INDEX PAGE PRESENTATION ............................5 TECHNICAL SPECIFICATIONS ....................... 7 PACKING LIST ............................7 OPERATION ..............................8 CONNECTION AND PREPARATION OF THE MICROPHONE BASE ..........9 5.1. S ......................... 10 ELECT MESSAGE START TONE 5.2.
-
Page 5: Presentation
TEMA TELECOMUNICAZIONI 1. PRESENTATION The AD696/BM paging microphone base can be connected to an AD615 Tema Encoder to launch announcements on the LAN network in Multicast channels to the network amplifiers or to the IP-SIP AD600 series loudspeakers of the SipComStage line. - Page 6 Paging Microphone Base for Announcements and Chime TEMA TELECOMUNICAZIONI VoIP SIP Amplifiers-Speakers Products and Accessories of the AD600 series “SipComStage” AA-39DL AD630 IP-SIP PoE 25W Horn Speaker Plug Power Supply 220Vac/12Vdc-1,0A. with 40W internal amplifier (2x20W) IP65 protection. AA-39D1A AD635 DIN Power Supply 220Vac/15Vdc-1,0A.
-
Page 7: Technical Specifications
Paging Microphone Base for Announcements and Chime TEMA TELECOMUNICAZIONI 2. TECHNICAL SPECIFICATIONS Microphone capsule Electret condenser Polar diagram Cardioid Frequency response 50 ÷ 16.000 Hz Output impedance 150 Ohm Sensitivity -40dB (0dB 1V/Pa @1Khz) Controls “Chime/PTT” button, “Background Music” switch... -
Page 8: Operation
Tema Telecomunicazioni paging sound system. AD696/BM allows to one operator to transmit a message to a network of IP speakers for the purpose of alerts or announcements, presents useful automatic functions for the announcement and different chime signals to choose,... -
Page 9: Connection And Preparation Of The Microphone Base
The AD696/BM microphone base is powered by the AD615/S system to which it must be directly connected. Insert the 8-pole plug connector of the integral cable connected to AD696/BM into the black RJ45 socket on the AD615/S module as clearly indicated in the photos below. -
Page 10: S Elect Message Start Tone
Paging Microphone Base for Announcements and Chime TEMA TELECOMUNICAZIONI 5.1. Select message start tone Nella tabella qui sotto riportata si trovano le impostazioni del banco di selezione dei toni di avviso. SW4 DESCRIPTION ** DURATION No message start tone 0 sec...
