Anti-Corrosion Network Box Camera
Quick Start Guide
UD04358B
0504051070109
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UD04358B and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION UD04358B

Summary of Contents for HIKVISION UD04358B

  • Page 1 Anti-Corrosion Network Box Camera Quick Start Guide UD04358B 0504051070109...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
  • Page 4 Network Box Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules.
  • Page 5 Network Box Camera·Quick Start Guide 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
  • Page 6 Network Box Camera·Quick Start Guide Warnings Follow these Cautions Follow these safeguards to prevent precautions to prevent serious injury or death. potential injury or material damage. Warnings ● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. ●...
  • Page 7 Network Box Camera·Quick Start Guide ● If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center. Cautions ● Make sure the power supply voltage is correct before using the camera.
  • Page 8 Network Box Camera·Quick Start Guide ● While in delivery, the camera shall be packed in its original packing, or packing of the same texture. ● Regular part replacement: a few parts (e.g. electrolytic capacitor) of the equipment shall be replaced regularly according to their average enduring time.

  • Page 9: Table Of Contents

    Network Box Camera·Quick Start Guide Table of Contents 1 Appearance Description ..............9 2 Installation ..................11 2.1 Default Parameters............12 2.2 Power Supply of the Housing ........12 2.3 Cable Connection ............13 2.3.1 Type I Housing Wiring ......... 14 2.3.2 Type II Housing Wiring ........

  • Page 10: Appearance Description

    Network Box Camera·Quick Start Guide 1 Appearance Description The anti-corrosion network box camera can be categorized into three types: Type I anti-corrosion network box camera is equipped with built-in heater and fan modules, as shown below. Figure 1-1 Overview of Type I Camera Type II anti-corrosion network box camera is equipped with wiper, built-in heater and fan modules, as shown below.
  • Page 11 Network Box Camera·Quick Start Guide Figure 1-3 Overview of Type III Camera...

  • Page 12: Installation

    Network Box Camera·Quick Start Guide 2 Installation Before you start ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12V DC or 24V AC, please make sure your power supply matches with your camera.

  • Page 13: Default Parameters

    Network Box Camera·Quick Start Guide Default Parameters The default RS-485 parameters of the bracket are listed below: Baud Rate: 9600 Protocol: Pelco-D Address Bit: 0 If ABF function is supported by the network camera, please refer to 3.2 and disable ABF function for wiper control and PTZ control. Select the power adapter according to specific requirement.

  • Page 14: Cable Connection

    Network Box Camera·Quick Start Guide 2.3 Cable Connection According to different places and environment for the housing installation, it is required to perform the investigation and programming before operating the wiring for the safe and stable power supply and wiring. During the wiring, take the following advices: ...

  • Page 15: Type I Housing Wiring

    Network Box Camera·Quick Start Guide 2.3.1 Type I Housing Wiring Black 12V DC- Camera Red 12V DC+ 24V AC Input Heater Figure 2-1 Type I Housing Wiring Steps: 1. Connect the cables of 24V AC power supply (power input) to the housing input terminal.

  • Page 16: Type Ii Housing Wiring

    Network Box Camera·Quick Start Guide  If the camera does not support 12V DC power-supply, an additional power adapter should be purchased. 2.3.2 Type II Housing Wiring Yellow RS485- Orange RS485+ Camera Black 12V DC- Red 12V DC+ 24V AC Input Heater Figure 2-2...

  • Page 17: Type Iii Housing Wiring

    Network Box Camera·Quick Start Guide 4. After connecting the camera, set the RS-485 parameters to be Baud Rate: 9600, Protocol: Pelco-D, Address Bit: 0.  Type II housing is equipped with fan (Power 4W) and wiper functions. A 24V AC power supply is required (purchased separately) for the proper use of device.
  • Page 18 Network Box Camera·Quick Start Guide Black 12V DC- Camera Red 12V DC+ 24V AC Input Heater Figure 2-3 Type III Housing Wiring Steps: 1. Connect the cables of 24V AC power supply (power input) to the housing input terminal. 2. Connect the power output cables to the camera. The power output is 12V DC, and the positive/negative terminals should be distinguished.

  • Page 19: Setting The Network Camera Over The Lan

    Network Box Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 20: Activating The Camera

    Network Box Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation.

  • Page 21: Activation Via Sadp Software

    Network Box Camera·Quick Start Guide Figure 3-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 22 Network Box Camera·Quick Start Guide Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera. Steps: 1. Run the SADP software to search the online devices. 2.

  • Page 23: Modifying The Ip Address

    Network Box Camera·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 24 Network Box Camera·Quick Start Guide Steps: 1. Run the SADP software. 2. Select an active device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Figure 3-5 Modify the IP Address...
  • Page 25 Network Box Camera·Quick Start Guide Note: You can enable the Hik-Connect service for the device during activation. Refer to Chapter 5.1 for detailed information. 4. Input the admin password and click Modify to activate your IP address modification. The batch IP address modification is supported by the SADP. Refer to the user manual of SADP for details.

  • Page 26: Accessing Via Web Browser

    Network Box Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 27 Network Box Camera·Quick Start Guide 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.

  • Page 28: Operating Via Hik-Connect App

    Network Box Camera·Quick Start Guide 5 Operating via Hik-Connect App Purpose: Hik-Connect is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so Note: Hik-Connect service is not supported by certain camera models. Enable Hik-Connect Service on Camera Purpose: Hik-Connect service should be enabled on your camera before using...

  • Page 29: Enable Hik-Connect Service Via Web Browser

    Network Box Camera·Quick Start Guide Figure 5-1 Verification Code Setting (SADP) Note: The verification code is required when you add the camera to Hik-Connect app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. 5.1.2 Enable Hik-Connect Service via Web Browser Before you start: You need to activate the camera before enabling the service.
  • Page 30 Network Box Camera·Quick Start Guide Steps: 1. Access the camera via web browser. Refer to Chapter 4. 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access Figure 5-2 Platform Access Configuration (Web) 3. Select Platform Access Mode as Hik-Connect. 4.

  • Page 31: Hik-Connect Setup

    Network Box Camera·Quick Start Guide Hik-Connect Setup Steps: 1. Download and install the Hik-Connect app by searching “Hik-Connect” in App Store or Google Play 2. Launch the app and register for a Hik-Connect user account. 3. Log in Hik-Connect app after registration. Adding Camera to Hik-Connect Before you start: You need to enable the Hik-Connect service on camera before...
  • Page 32 Network Box Camera·Quick Start Guide You can find the QR code on the camera or on the cover of the Quick Start Guide of the camera in the package. Figure 5-4 Scan QR Code Note: If the QR code is missing or too blur to be recognized, you can also add the camera by tapping the icon and inputting the camera's serial number.

  • Page 33: Initializing The Memory Card

    Network Box Camera·Quick Start Guide Initializing the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection.
