CSS AssistX Mobil Series Quick Manual

AssistX
Features
AssistX ® Mobil is a mobile call system for one or more users. The set consists of a transmitter and a
receiver. To trigger a call different switches and sensors can be used.
Beside the common switches and sensors with normally cosed (NO) or normally open (NO) contact, all
active sensors of the AssistX family can be used: AssistX
proximity sensor, AssistX
8 8 6
Transmitter:
Connections:
AssistX ® Port (pink) for many common
•
sensors/switches (jack plug 3.5mm / 1/8")
Connect Sensor/Switch:
•
Plug in the sensor at pace to avoid misidentification
Unplug Sensor/Switch:
•
For safety reason a call is triggered whenever the sensor is plugged off. To avoid triggering a call,
switch off the transmitter before disconnecting the sensor.
USB-Socket
• Power supply, battery charge
AssistX Mobil Quick Guide 1.4 ENG
® Mobil
® IR one infrared sensor or AssistX
Min. distance 50 cm (20") !!
9
2
4
Transmitter
10
® AS one acoustic sensor, AssistX
® RX one radio receiver.
1
5
5
3
4
Receiver
1
LED
2
Call Button
3
Confirm/OK-Button
4
ON-OFF-Button
® ProX2
10
6
7
5
Menu- up/down
6
USB socket
7
Output socket
8 8
AssistX Port -
®
Sensor-/Switchport
9
Cornfirmation Light
10
Reset (restart)
Vers.1.4
