Installation Manual
Getting Started
With Movi for IBM Lotus Sametime users can enjoy both point to
point and multipoint video through their IBM Lotus Sametime client.
Movi for
Video calls can be made from the IBM Lotus Samtime client to
other Sametime users, and also to meeting rooms with video appli-
IBM Lotus Same-
ances.
time
Movi for Sametime uses TMS for multipoint video calls to integrate
the enterprises' videoconferencing infrastructure with IBM's most
powerful instant messenger application.
Please see
http;//www.ibm.com/lotus/sametime
for more informa-
tion about IBM Lotus Sametime.
Functional Overview
The components to be installed on the Sametime server will inte-
grate TANDBERGs Movi client in to the Sametime Connect clients.
When enabled users can simply select a buddy, and press the icon
for starting a video chat.
TANDBERG Movi for Sametime supports both point to point and
multipoint conferences. It is also possible to dial into video meeting
D4068 Rev.4
rooms hosted on appliances available in these rooms.
This document is not to be reproduced in whole
or in part without permission in writing from:
Advertisement
Table of Contents
Related Manuals for TANDBERG D4068
Summary of Contents for TANDBERG D4068
-
Page 1: Functional Overview
When enabled users can simply select a buddy, and press the icon for starting a video chat. TANDBERG Movi for Sametime supports both point to point and multipoint conferences. It is also possible to dial into video meeting D4068 Rev.4 rooms hosted on appliances available in these rooms. -
Page 2: Table Of Contents
Table of ConTenTs Requirements Server software requirements Optional meeting room service requirements Optional multiparty requirements Client software requirements Installing Movi for IBM Lotus Sametime Server installation Configuring the Sametime environment Configuring the video integration Video client installation Troubleshoot Appendix 19... -
Page 3: Requirements
This documentation is written towards a Windows based installation of Movi for IBM Lotus Sametime as TANDBERG only supports installation of the Sametime integration on Windows Servers. The Sametime Connect client is multi-platform, but TANDBERG only supports installations on Windows clients using the stand-alone .exe version of the client. -
Page 4: Installing Movi For Ibm Lotus Sametime
Additional permissions for the Multipart installation • Ability to create accounts on the TMS server Setting up TANDBERG Management Suite and adding video systems The multipart installation of Movi for IBM Lotus Sametime relies on an existing TMS v11.7.1 or newer installation. The TMS server should be configured and operational before attempting to add the Sametime integration components. - Page 5 Any video conferencing systems that Meeting Room service will provide in the Sametime clients must be operational in TMS before they are available to Lotus Sametime Clients.
-
Page 6: Server Installation
Server installation The Domino Server must be stopped prior to starting the Installation Wizard. To complete the installation, the Domino Server must be restarted - the Installation Wizard will prompt you if you want the server restarted automatically. Installing Movi for Sametime on the IBM Lotus Sametime server Copy the installation files and extract them on the Sametime Server. - Page 7 TCSPI is the multiparty feature, that lets you have mutiple participants join the same video chat. Only applicable if your organizations has a TANDBERG MPS. Select the features you want to install. Choose the location for where to install the configuration tool.
- Page 8 Click “Next” to start copying files. You will now be promted with an option to restart the domino service to activate the Movi for IBM Lotus Sametime integration. The installation is now complete. Click “Finish” to exit the installation wizard.
-
Page 9: Configuring The Sametime Environment
Configuring the Sametime environment Several Domino specific steps are required after the installation wizard is complete in order to complete the Movi for Sametime installation procedure. Update the URL for UIM Provisioning field Open the stconfig.nsf database from the Lotus Notes/Administrator client. Open the database by File->Database ->... - Page 10 of Domino Accounts’ feature of the configuration utility. Complete the follow- ing steps if you wish to enable this web service. Open Domino Administrator and select the server that stores the databases or templates that you want to sign. On the Files tab, select the data folder and select the file “TandbergConfigTools”...
- Page 11 Update MeetingServices database Open the stconfig.nsf database from the Lotus Notes/Administrator client. Open the database by File->Database -> Open… – Choose the Sametime server’s name in the dropdown list (server), and enter stconfig.nsf in the Filename field – Press Open Open the MeetingServices Form by highlighting By Form, and double click MeetingServices in the Form Name column...
- Page 12 Update the two fields Audio Bridge Services and Telephony Services, set both to true. Click ctrl+s to save Restart your Domino server.
-
Page 13: Configuring The Video Integration
Configuration tool Launch the configuration tool that comes with Movi for Sametime from Start ->All Programs -> TANDBERG -> Movi for Sametime configuration tool. Video configuration The video settings describe the general settings that apply to all the features, point to point, Meeting room service and multipart (TCSPI). - Page 14 Only available if either multipoint (TCSPI) or Meeting room service module is installed Only available if Meeting room service module is installed The address of the TMS server. E.g. tms.tandberg.com A windows user account with TMS access. Notice! This user is required to...
-
Page 15: Video Client Installation
Video client installation When exporting a TMS system to the Meeting Room service, a Sametime account is required for this system. If the Create account automatically option is enabled, A Sametime account is automatically created in the Domino Direc- tory. You will be prompted for a password to assign to this account’. If the create account option is unchecked, you will be prompted for the username and password of the existing Sametime account to associate to this system. - Page 16 The client interface will automatically open and the user will be prompted to install the ActiveX component. Install the component and acknowledging any security warnings. Once this is completed, users will see the video window become active. Close the web browser, and the component setup is com- plete.
-
Page 17: Troubleshoot
# Note that the ConsoleHandler also has a separate level # setting to limit messages printed to the console. .level=FINEST net.tandberg.tms.integration.caius.tcspi.level=FINEST net.tandberg.tms.integration.caius.tcspi.post.level=FINEST This will create a verbose tcspi log (telephony_0.log), found in the Trace directory of the <Domino> directory, typically c:\program files\lotus\domino\ Trace\telephony_0.log... - Page 18 The log entries by the Movi for IBM Lotus Sametime plugin is identified by “[net.tandberg.tms.integration.caius.” The entries are written to the following format [date and time] [entry written by ID] loglevel Message To reset the logging, set the loglevel values to INFO.
-
Page 19: Appendix
Appendix Suggested configuration values Level Parameter Low quality Video Bandwidth Frame rate Medium quality Video Bandwidth Frame rate High quality Video bandwiudh Frame rate Value...
