All manuals and user guides at all-guides.com
5.5" B/W Television with 7 Channel
Weather Band and AM/FM Stereo Radio
Instruction Manual
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lighting flash with arrowhead symbol within an equilateral triangle
is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the products's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
JK-3030
http://www.jwin.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for jWIN JK-3030
Summary of Contents for jWIN JK-3030
- Page 1 All manuals and user guides at all-guides.com 5.5" B/W Television with 7 Channel Weather Band and AM/FM Stereo Radio Instruction Manual JK-3030 http://www.jwin.com CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
- Page 2 All manuals and user guides at all-guides.com The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK. DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
- Page 3 All manuals and user guides at all-guides.com 6A. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart com- bination to overturn. 7. Wall or Ceiling Mounting – The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer.
- Page 4 All manuals and user guides at all-guides.com 17. Object and Liquid Entry – Care should be taken so that objects do not fall and liquids are not spilled into the unit through openings. 18. Damage Requiring Service – The appliance should be serviced by qualified service personnel when: A.
- Page 5 All manuals and user guides at all-guides.com " " $ % & % & ' 1. HEADPHONE JACK 11. SPEAKER GRILL 2. POWER INDICATOR 12. DC JACK 3. TV MONITOR ANTENNA TELESCOPIC 4. FUNCTION SELECTOR 14. EXTERNAL TV ANTENNA JACK 5.
- Page 6 All manuals and user guides at all-guides.com RADIO OPERATION – Press the Power Switch down to turn on the unit and the Power indicator light up. – Set Function Selector to “RADIO” position. – Select the desired radio frequency band with Band Selector. For FM Stereo, FM Stereo LED light on.
- Page 7 All manuals and user guides at all-guides.com SPECIFICATION Power Supply: Radio Frequency Coverage: 530 - 1710 KHz 88 - 108 MHz Weather Band Frequency Coverage: CH 1 162.550 MHz CH 2 162.400 MHz CH 3 162.475 MHz CH 4 162.425 MHz CH 5 162.450 MHz CH 6...
