- Page 1 Visual Quick Reference English Trendsetter NEWS SA ® www.creo.com 653-00979A-EN-A Copyright © 2005 Creo Inc. All rights reserved. Internal 732-00041A-EN-RevA February 2005...
- Page 2 Trendsetter NEWS SA Operational Lights and What They Mean Operator interface lights Operator Interface Lights Operator Action Imaging Light Flashing green Wait—the device is imaging a plate. Semi-automatic mode—load one or two plates for imaging. Load Light Flashing green Semi-automatic mode—wait, the device is unloading a plate.
- Page 3 Imaging Plates Using Different Workflows Trendsetter NEWS SA Trendsetter NEWS SA Prinergy In Prinergy, click OK to submit the file. The output device receives the job in Print Console. Brisque In Brisque, click Submit to submit the file. The output device receives the job in Print Console.
- Page 4 Trendsetter NEWS SA Imaging a Plate Ensure the device is ready. In Print Console: a. Click Open to submit the file. b. Ensure that the correct media CAUTION: Wear protective is available for loading. gloves when handling plates.* The load light glows green.
- Page 5 * Procedures for these items are included in this visual quick reference guide. ** Optional equipment—media dependent. Note: This document is not intended as a substitute for the Trendsetter NEWS SA Operator Guide. Refer to the operator guide for detailed procedures.
- Page 6 Trendsetter NEWS SA Replacing the Air Supply Filters Replacing the 5 Micron Filter WARNING: Remove air pressure from the device before replacing an air filter.* Unscrew the bowl by pulling the tab down and turning the bowl to the left.
- Page 7 Cleaning Inside the Output Device Trendsetter NEWS SA Trendsetter NEWS SA Cleaning the Edge Detection Strip WARNING: Risk of electrical shock if liquids are alowed to run freely into the output device.* Rotate the drum to expose the two edge...
- Page 8 Trendsetter NEWS SA Replacing the Intake Air Filter Remove the fan box panel: a. Push the upper corners of the fan box panel in until you hear both latches click. b. Lift the fan box panel up and out. Fan box panel Remove the old intake air filter...
- Page 9 Removing a Flyoff Trendsetter NEWS SA Trendsetter NEWS SA The device suspends activity. Open the front panel: b. Rotate the two latches and lift the front panel. CAUTION: Wear protective gloves when handling plates.* a. In Print Console software, unlock the front panel.
