- Page 1 Visual Quick Reference English Trendsetter 400/800 ® www.creo.com 653-00953A-EN-A Copyright © 2005 Creo Inc. All rights reserved. Internal 732-00035A-EN-RevA April 2005...
- Page 2 Trendsetter 400/800 Operational Lights and What They Mean Operator Interface lights Operator Interface Lights Operator Action Imaging Light Flashing green Wait—the device is imaging the plate. Place a plate on the load ramp. Load Light Steady green The green light stays on until the plate is unloaded.
- Page 3 Imaging Plates Using Different Workflows Trendsetter 400/800 Trendsetter 400/800 Prinergy In Prinergy, click OK to submit the file. The output device receives the job in Print Console. The output device receives the job in Print Console. Brisque In Brisque, click Submit to submit the file.
- Page 4 Trendsetter 400/800 Imaging a Plate Ensure the device is ready. In Print Console: b. Ensure that the correct plate a. Click Open to submit the file. is available for loading. CAUTION: Wear protective gloves when handling plates.* The load light flashes green.
- Page 5 * Procedures for these items are included in this visual quick reference guide. ** Media dependent Note: This document is not intended as a substitute for the Trendsetter 400/800 Operator Manual. Refer to the operator manual for detailed procedures. Software may display differently depending on the version of Print Console in use.
- Page 6 Trendsetter 400/800 Replacing the Air Supply Filters Replacing the 5 Micron Filter WARNING: Remove air pressure from the device before replacing an air filter.* Pull the filter tab down, rotate the bowl a quarter turn (either Clean inside the bowl.
- Page 7 Cleaning Inside the Output Device Trendsetter 400/800 Trendsetter 400/800 WARNING: Risk of electrical shock if liquids are Cleaning the Edge Detection Strip alowed to run freely into the output device.* CAUTION: Be careful not to bump your head on the raised panel.*...
- Page 8 Trendsetter 400/800 Replacing the Air Intake Filter Remove the right-end access panel: a. Use a flathead screwdriver to rotate both screws 90° counterclockwise. b. Tilt the panel back and lift it off its locating pins. Right-end Remove the old air intake filter access panel from the frame.
- Page 9 Removing a Flyoff Trendsetter 400/800 Trendsetter 400/800 Open the front panel: The device suspends activity. a. Rotate the two latches on the b. Lift the front panel. front panel to the vertical position CAUTION: Wear protective (90° counterclockwise). gloves when handling plates.*...
