40-6537 Service Manual 40-6537 Auto-leveling Rotating Laser Service Manual Item Description Pages Introduction Overall Unit Assembly Upper Cover Assembly Housing Assembly Main Body Assembly Core Assembly Base Assembly Calibration 6-14 Horizontal Mode Calibration 3.1.1 Quantifying Accuracy Error 3.1.2 Characterizing Accuracy Error 3.1.2.1... -
Page 2: Description
In reality, only component parts or modules would be replaced during a repair. Given this, procedures discussed in this manual should be adjusted according to the repair being made. 2.0 Overall Unit Assembly (40-6537) Item JLT Part # Description AP1690 ST2.9 x 10 Cross Plate Tapping... - Page 3 40-6537 Service Manual 2.1 Upper Cover Assembly (AP1939) Item JLT Part # Description AP1947 Upper Cover AP1948 #11 Connecting PCB AP1843 ST2.2 x 6.5 Cross Plate Tapping Screw Remove Rechargeable #11 PCB (2-2) by removing retaining screws (2.3) 2.2 Housing Assembly (AP1944)
-
Page 4: Main Body Assembly
40-6537 Service Manual 2.3 Main Body Assembly (AP1941) Item JLT Part # Description AP1513 M3 x 8 Cross Plate Screw AP1955 Top Plate Assembly AP1883 3MM Elastic Gasket AP1956 Core Assembly AP1957 Tension Spring AP1958 #1 Main PCB AP1616 M2.5 x 5 Cross Plate Screw... - Page 5 40-6537 Service Manual 2.4 Core Assembly (AP1956) Item JLT Part # Description 6.4.1 AP1647 M2x 5 Cross Plate Screw 6.4.2 AP1969 Rotary Head Part 6.4.3 AP1696 M2x 10 Cross Plate Screw 6.4.4 AP1970 Prism Assembly 6.4.5 AP1971 Locking Nut 6.4.6...
-
Page 6: Base Assembly
While Manual-leveling, Self-leveling, and Automatic-leveling (motor driven) devices have different mechanisms that require calibration, there are similarities with optics that is consistent regardless of the leveling mechanism. This section of the service manual discusses calibrations specific to the 40-6537. Each item discussed is shown below. -
Page 7: Quantifying Accuracy Error
40-6537 Service Manual 3.1. Horizontal Mode Operation In this mode of operation, the instrument is self-leveling, where by a major factor of accuracy is how well the leveling compensator is balanced. Different types of errors require different methods of calibration. These errors are easily characterized by placing the instrument on a flat surface following the guidelines below, and running the instrument with the rotating head continuously rotating 360°. - Page 8 40-6537 Service Manual 3.1.2. Characterize the type of error Use the following rules to determine what to of accuracy error the instrument for test has, and reference the stated section to adjust for it. Note that the unit my have a combination of different types of errors to adjust for, in which case, multiple calibration must be performed.
-
Page 9: Oblique Error
40-6537 Service Manual 3.1.2.1. Oblique error This type of error occurs when leveling compensator does not hang straight (as illustrated to the right), i.e. is not properly balanced. When the laser spins, it actually rotates on a plain that is not level, i.e. - Page 10 2. X-axis calibration SLO PE Press the key one time and verify that the X-direction LED on the keypad of the 40-6537 flashes, indicating that it has entered the self-calibration mode on the X-direction. Press the key to adjust the laser beam up or down to coincide with the reference line.
- Page 11 40-6537 Service Manual Coarse Adjust - Calibration via Internal Leveling Sensors If the error is more than ±0.5mm/m, it will need to make calibration by adjusting the sensor. The details are as follows: Reference point Reflected prism Display of the adjusting fixture for sensor...
-
Page 12: Taper Error
40-6537 Service Manual 3.1.2.2 Taper Error Taper error results when the prism base module (discussed in section 2.4, item 6.4.4) does not reflect the laser light exactly 90° (i.e. non-perpendicularity between the rotating line Taper error and the rotating axis). The end result is a laser rotating surface that is not a plane, but a tapered one as shown in the figure to the right. -
Page 13: Wave Error
40-6537 Service Manual 3.1.2.3 Wave Error This error occurs when the rotating laser surface is not a plane, but a turn up one as shown in the figure to the right. The rotating beam projected on the wall is crooked, Wave error similar to waviness, which is caused by the unbalance of rotating head. -
Page 14: Vertical Mode Operation
In this mode of operation, the rotating laser surface is a plumb plane, while the laser line projected from the top is in projecting horizontal. While in this mode, the instrument is manually level, meaning that accuracy is a function of how accurately the vial is calibrated. The 40-6537 is not designed for Vertical Mode Operation. 3.3. Alarm Calibration The alarm function is made up of 3 components, the 2 alarm PCB’s (7-15-17, 7-14-13) and the buzzer (10-3). -
Page 15: Troubleshooting Guide
40-6537 Service Manual 5.0. Troubleshooting Guide Symptom Cause Corrective Action Battery case is loose Change battery box 1# control board is defective Change 1# control board Battery is low Charge/Change Battery Power switch is defective Change Power Switch Unit doesn’t turn on...
