2. Technical data
Supply voltage
Power consumption
Fuse
Inputs
Outputs
Protection degree
Mode of operation
Insulation class
Ambient temperature
Power reserve
Installation
Housing
Dimensions
Weight
Conformity
3. Safety instructions
Danger of electrocution!
The controller is to be assembled, electrically installed, commissioned, inspected and repaired by
trained, competent and authorised persons (qualified electricians as per DIN VDE 1000-10 and
BGV A3) only!
Observe all applicable guidelines and regulations of the local electricity supplier!
DANGER
Before beginning installation or repair work on electrical equipment, always ensure complete
disconnection from the mains and secure against reactivation!
Do not work on live parts!
The controller may only be installed and operated in:
dry environments which are not potentially explosive
closed rooms
rooms with a temperature between 0 °C and + 50 °C
230 V AC 50 Hz
2.4 VA
1.6 AT, microfuse 5 mm x 20 mm
4 inputs:
temperature sensor: Pt1000 (-20 °C to +150 °C)
2 electromechanical relays: each 1 A, 250 V AC (ε)
IP 20 as per DIN EN 60529 (VDE 0470-1)
type 1 Y (as per DIN EN 60730-1)
2
0 °C to + 50 °C
> 10 years at + 20 °C, with lithium battery
wall-mounted
plastic, PC / ABS
170 mm x 170 mm x 55 mm
0.65 kg
The solar controller meets the requirements of the Electromagnetic Compatibility
Directive (2004/108/EC), the Low Voltage Directive (2006/95/EC) and the har-
monised standards DIN EN 60730-1 and DIN EN 60730-2-9. It bears the CE
label.
