Setting the additional functions
10.8.

Additional function: temperature comparison

Sensor inputs and relay outputs can be freely selected for an additional temperature comparison function.
Level Display
VSA
E3-8 / 1
VSB
E3-8 / 2
VR
E3-8 / 3
VDE
E3-8 / 4
VDA
E3-8 / 5
Function
Selection of the first sensor
input.
0: no sensor allocated (function
is not enabled)
1 to 4: sensor is allocated
(function is enabled)
The number of any sensor
which is still free is accentuated
by flashing underscore lines. If
the selected sensor is already
assigned to another function,
the corresponding number is
displayed within brackets.
Selection of the second sensor
input (see above).
Selection of the relay output.
Any relay can be selected. If the
selected relay is already as-
signed, the functions are com-
bined in an OR relationship.
Switch-on temperature differ-
ence for the temperature com-
parison function (cannot be set
to less than VDA + 1 K).
Switch-off temperature differ-
ence for the temperature com-
parison function (cannot be set
to greater than VDE - 1 K).
Factory Range
setting
0 0 to 4
0 0 to 4
0 0 to 2
2 K 1 K to 20 K
1 K 1 K to 20 K
Selection
