- Page 1 REMKO RKW 1000 – 9800 INOX Stainless Steel Chiller Operation Technology Spare Parts REMKO – powerful like a bear Edition GB – M11...
-
Page 3: Table Of Contents
Subject to alterations! REMKO Stainless Steel Chiller RKW 1000 INOX / 1600 INOX / 2600 INOX 3600 INOX / RKW 4500 INOX / 8000 INOX / 9800 INOX Contents... -
Page 4: Unit Description
◊ Make sure that the unit is kept at a safe distance REMKO chillers are suitable for almost every type of ap- from flammable materials. plication when used with the right consumers if the pri- ◊... -
Page 5: Transport And Packaging
◊ Operate the units exclusively within the permissible Instructions: operating ranges. ◊ When shipped, the units are packaged in a box and ◊ Do not expose the unit to direct streams of water mounted on a palette. High-pressure cleaners, etc. ◊... - Page 6 Regulation Value Display CH–DIN regulation of all RKW INOX units The value display shows the target value in degrees The CH–DIN microprocessor regulates the chiller for all with one decimal place in Celsius. It can also display: INOX units. It is located in the electrical switch box of ◊...
- Page 7 C2–DIN Additional Regulations for Models RKW 3600 ON/OFF ON/OFF/RESET Button RESET and higher This button is used to switch the unit on and off. If the For chillers with cooling capacities higher than 26 kW, alarm has been set off and the unit has to be manually the cooling capacity is divided among two cooling cy- reset, this button is pressed to prevent further alarms cles.
- Page 8 Determining the Operating Mode (Status) The Status menu is used to determine the current operating mode of the various system components such as oper- ating hours, outputs currently set, the current actual values of the sensor inputs and any current malfunctions. Pressing the STATUS button takes you to the Status menu (Status LED is lit up).
-
Page 9: Maintenance And Service
The program- company from REMKO GmbH &Co. KG. ming level can be exited by pressing the SET button a third time. The settings are saved and the return tem- perature is displayed again. -
Page 10: Shutting Down The Unit
Temporary shutdown be disassembled by authorised service centres. REMKO GmbH & Co. KG or your contract partner would If the unit is to be taken out of operation for a longer pe- be happy to provide you with the name of a service cen- riod of time, for example, over the winter, proceed as tre in your area. -
Page 11: Troubleshooting
Troubleshooting This unit has been designed based on state-of-the-art manufacturing methods and it has been tested repeatedly to ensure that it is working properly. However, should problems occur, refer to the following list. Problem Alarm Possible cause Check Remedy Are all other electrical components Check voltage and wait for the Power failure working? -
Page 12: Technical Data
Technical Data Type RKW INOX 1000 1600 2600 3600 4500 8000 9800 Cooling capacity 10,0 16,0 25,6 35,9 44,3 78,0 98,0 Air performance max. m³/h 3000 6200 10000 17000 19000 35000 39000 Number of fans / diameters -/mm 2/450 2/450 1/630 2/630 2/630... -
Page 13: Dimensions
Dimensions RKW 1000 INOX / 1600 INOX RKW 2600 INOX RKW 3600 INOX / 4500 INOX RKW 8000 INOX / 9800 INOX Model size 1000 INOX 1600 INOX 2600 INOX 3600 INOX 4500 INOX 8000 INOX 9800 INOX 1150 1150... -
Page 14: Assembly Instructions For Service Personnel
RKW 1000 / 1600 INOX Unit Assembly 1000 The REMKO RKW INOX chillers have been designed and built for outside setup. Because a lot of heat is ex- pelled to the surroundings, make sure that when you se- lect a location for setup, air can flow freely in and out of the unit. - Page 15 RKW 3600 / 4500 INOX with storage module Vibration absorbers RKW 1000 - 4500 INOX RKW 8000 – 9800 INOX 13Ø 8Ø 1000 M12 x 35 Attachment locations for chillers RKW 3600 / 4500 INOX without storage module RKW 1000 / 1600 INOX 1000 RKW 2600 INOX RKW 8000 / 9800 INOX...
- Page 16 Hydraulic connections Connecting the water pipes The hydraulic connections are located on the back of The RKW 1000, 1600 and 2600 INOX models in this the units. series are equipped with a cold water storage module as a compact unit. The 3600, 4500, 8000 and 9800 The RKW 1000 and 1600 INOX units are ready to be INOX models are supplied in this series without hydrau- connected upon shipment.
-
Page 17: Storage Modules For Rkw 3600 To 9800 I
Hydraulic Connections Hydraulic connection RKW 8000 / 9800 INOX RKW 1000 / 1600 INOX Incoming water Outgoing water Incoming water Outgoing water Storage module for RKW 3600 to 9800 INOX For the RKW 3600, 4500, 8000 and 9800 INOX models, RKW 2600 INOX it is not necessary to use a storage tank for certain types of use... - Page 18 Storage Module Technical Data 3600 4500 8000 9800 Storage module for RKW INOX Storage contents 2 x 216 Number of pumps Incoming water / Outgoing inch 1½ 1½ water Filling connection inch Operating pressure max. Rated volume current water m³/h 13.4 16.9 Minimum volume current...
- Page 19 Assembling the storage module Characteristic curve of the pump RKW 3600 / 4500 INOX storage module 2 1. Remove the transport packaging and, if applicable, assemble the vibration absorbers onto the bottom of the storage module. If the storage module is to be placed below the chiller, the vibration absorbers do not need to be at- tached.
-
Page 20: Cable Remote Control
Antifreeze to prevent freezing Electrical connection of the cable remote control During cold seasons of the year, it is possible that the The remote control comes with an operating module water in the chiller will freeze at temperatures below 0°C TS-W, the additional regulation module CS-DIN/TTL which can cause damage, for example, to the plate heat and an interface line. -
Page 21: Electrical Connection
Electrical Connection All electrical connections such as power input, cable re- mote control, etc., are to be made in the switch box of Electrical installations may only be performed by the unit. The lines to be laid must be guided through the authorised service personnel. - Page 22 Wiring Diagram RKW 1000 INOX / 1600 INOX ST 1: Temperature sensor Incoming water ST 2: Temperature sensor Outgoing water Microprocessor Differential ST 5: Temperature sensor regulation pressure Verflüssiger monitor IN- TERNAL HP Pressure absorber High-pressure LP Pressure absorber Low pressure...
- Page 23 EXTERNAL INTERNAL Connecting the Remote Control RKW 1000 INOX to 9800 INOX Transformer 220 / 12 V~ in the switch box RKW L1 N CH – DIN regulation / Additional module for C2 – DIN regulation...
-
Page 24: Hydraulic System
Electrical Wiring Diagram RKW 8000 INOX / 9800 INOX ST 1: Temperature sensor ST 2: Temperature sensor Frequency Microprocessor ST 5: Temperature sensor block regulation HP Pressure absorber High pressure LP Pressure absorber Low-pressure Compressor 1 Compressor 2 Additiona module Compressor 3 Winter regulation Compressor 4... -
Page 25: Initial Operation
Summer Operation Cooling Only Winter Operation Cooling and Heating Initial Operation ◊ Make sure that the temperature sensors (condenser, supply and discharge / protection against freezing) are in the correct positions and that the water lines Checks prior to operation: are connected properly to the input and output. -
Page 26: Environment And Recycling
For the guarantee to be valid, the purchaser or his cus- tomer must completely fill out the "guarantee certificate" 15.If the factory setting has been changed, set the de- enclosed with all units and send it back to REMKO GmbH sired drainage temperature by setting the Parame- & Co. KG ter -02 to the target value, exit the parameter level and press the ON / OFF / RESET button twice. - Page 28 REMKO GmbH & Co. KG Klima- und Wärmetechnik D-32791 Lage Im Seelenkamp 12 • D-32777 Lage PO Box 1827 • Phone +49 (5232) 606 - 0 +49 (5232) 606260...
