MOUVEX TRUCK SCREW COMPRESSOR
SAFETY, STORAGE, INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
Definition of safety symbols
This is a SAFETY ALERT SYMBOL.
When you see this symbol on the product, or in the manual,
look for one of the following signal words and be alert to the
potential for personal injury, death or major property damage.
Warns of hazards that WILL cause serious personal injury,
death or major property damage.
Warns of hazards that CAN cause serious personal injury,
death or major property damage.
Warns of hazards that CAN cause personal injury or property
damage.
Indicates special instructions which are very important and
must be followed.
REMARKS :
MOUVEX truck screw-type compressors MUST be installed in sys-
tems designed by qualified personnel. The installation MUST be in
compliance with local standards, national regulations and rules of
safety.
This manual is designed to permit installation and commis-
sioning of MOUVEX truck screw-type compressors and MUST
accompany the compressor.
Maintenance of MOUVEX screw-type compressors must ONLY
be carried out by qualified technicians. This maintenance must
meet local and national standards as well as all safety regula-
tions. Read this manual, including all instructions and warn-
ings, in full BEFORE any use of MOUVEX compressors.
Reading and the removal of the labels on the MOUVEX com-
pressor apply to approval.
NT 1401-X00 10 18 B200 Flow Control e
MODEL : B200 Flow Control
DANGER
WARNING
CAUTION
NOTICE

TABLE OF CONTENTS

1. OVERALL DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . .4
2. GENERAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.1 Principle of operation . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.2 Technical characteristics . . . . . . . . . . . . . . . . . . . . . . . .7
2.3 Operating ranges . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
3. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
3.1 B200 PF with truck power take-off . . . . . . . . . . . . . . .10
3.2 B200 PS with drive shaft . . . . . . . . . . . . . . . . . . . . . .12
3.3 B200 HY with hydraulic motor . . . . . . . . . . . . . . . . . .13
3.4 Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
4. USE OF COMPRESSOR . . . . . . . . . . . . . . . . . . . . . . . . . .17
4.1 Lubricant recommendations . . . . . . . . . . . . . . . . . . . .17
4.2 Filling of lubricant . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
4.3 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
5. MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
5.1 Maintenance schedules . . . . . . . . . . . . . . . . . . . . . . .18
5.2 Compressor oil change . . . . . . . . . . . . . . . . . . . . . . . .18
5.3 Inlet shaft replacement . . . . . . . . . . . . . . . . . . . . . . . .19
5.4 Warranty claims . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
6. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . .20
7. STORAGE CONDITIONS . . . . . . . . . . . . . . . . . . . . . . . . .20
7.1 Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
7.2 BSC2 oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
8. SCRAPPING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
9. COMPRESSORS FORM INFORMATION . . . . . . . . . . . . .21
10. CERTIFICATE OF CONFORMITY . . . . . . . . . . . . . . . . .22
ADDITIONAL DOCUMENTATION
The table below gives the list of instructions in addition
to this central instruction :
B200
application
Torque limiter
Air cooler
12R/10L
2/22
Page
Spare parts
list
NT 1401-AB00
NT 1401-AD00
PL 1401-X01
