- Page 1 Installation and operating instructions Joystick III Version: V3.20180409 3032258305-02-EN Read and follow these operating instructions. Keep these operating instructions in a safe place for later reference.
- Page 2 Company details Document Installation and operating instructions Product: Joystick III Document number: 3032258305-02-EN As of software version: 7.03 Original language: German Copyright © Müller-Elektronik GmbH & Co.KG Franz-Kleine-Straße 18 33154 Salzkotten Germany Phone: ++49 (0) 5258 / 9834 - 0 Fax: ++49 (0) 5258 / 9834 - 90 Email: info@mueller-elektronik.de...
-
Page 3: Table Of Contents
Table of contents Table of contents Product description Assembly instructions Fitting a joystick with a Sub-D connector Fitting a joystick with a CPC connector Fitting a joystick with a CPC connector and a CPC socket Configuring the joystick Operation Executing functions Changing the brightness of the LED Assigning functions Viewing functions... -
Page 4: Product Description
Product description Product description Joystick III Eight buttons Numbering of the buttons Side-mounted switch Rating plate [➙ 13] The joystick is an ancillary operating device which can rapidly access the functions of an ISOBUS job computer. The joystick is fitted with eight buttons and a single side-mounted switch, which enables switching between three levels. -
Page 5: Assembly Instructions
Assembly instructions Fitting a joystick with a Sub-D connector Assembly instructions The joystick is available in three versions: ▪ With Sub-D connector (item no.: 3032258305) – Variant for vehicles with additionally installed ISOBUS basic vehicle harness from Müller-Elektronik. ▪ With CPC connector (item no.: 3032258606) –... -
Page 6: Fitting A Joystick With A Cpc Connector
Assembly instructions Fitting a joystick with a CPC connector Fitting a joystick with a CPC connector Angle brackets Connector for connection to the vehicle's ISOBUS In-Cab- For attachment in the cabin Connector Procedure You fit the joystick as follows: 1. Fit the joystick next to the driver on the right. 2. - Page 7 Assembly instructions Fitting a joystick with a CPC connector and a CPC socket 2. Plug the connector into the ISOBUS in-cab-connector of your vehicle. 3. Connect the CPC socket to a CPC connector to connect the joystick to a terminal using an adapter cable. ⇨...
-
Page 8: Configuring The Joystick
Configuring the joystick Configuring the joystick Brightness for day or night mode: Selected auxiliary protocol Day mode Selected joystick number Cursor Function Meaning icon Switches between day and night mode Increase brightness Reduce brightness When configuring the joystick, you can make the following settings: ▪... - Page 9 Configuring the joystick If you don't know which protocol your system supports, you can test this by selecting protocol “AUX2”. If you can then assign functions [➙ 10] for the ISOBUS job computer to the joystick, your system supports Auxiliary 2. Otherwise, select protocol “AUX1”.
-
Page 10: Operation
Operation Executing functions Operation Executing functions Each button on the joystick can be assigned three functions. The position of the side-mounted switch determines the function which is performed when the button is pressed: Position of the switch Color of the LED Yellow Green Procedure... - Page 11 Operation Viewing functions You have selected the appropriate protocol when configuring the joystick. [➙ 8] Your ISOBUS job computer is connected to the vehicle's ISOBUS in-cab- connector. You have assigned functions to the joystick. [➙ 10] 1. Start the terminal. 2.
-
Page 12: Technical Specifications
Technical specifications Technical specifications of the joystick Technical specifications Technical specifications of the joystick Parameters Value Operating voltage 10.5 V to 16 V DC Temperature range -20°C to +70°C Current consumption 40 mA Protection rating IP20 Sub-D connector pin assignment Pin no. -
Page 13: Information On The Rating Plate
Technical specifications Information on the rating plate Information on the rating plate The nameplate is located on the underside of the joystick. Abbreviations on the rating plate Abbreviation Meaning Customer number If the product was manufactured for an agricultural machinery manufacturer, the agricultural machinery manufacturer's item number will be shown here. -
Page 14: Eu Declaration Of Conformity
EC Directive of Electromagnetic Compatibility 2014/30/EU. If alterations are made to the product without prior consultations with us, this declaration becomes invalid. Product name: ME_AR Joystick III 8+1 Taster ISO Sub-D Aux1/Aux2, abgedichteter Taster Item number: 3032258305...
