- Page 1 Installation and operating instructions ISOBUS-Joystick PRO Version: V2.20170628 3232258620-02-EN Read and follow these operating instructions. Keep these operating instructions in a safe place for later reference.
- Page 2 Company details Document Installation and operating instructions Product: ISOBUS-Joystick PRO Document number: 3232258620-02-EN Original language: German Copyright © Müller-Elektronik GmbH & Co.KG Franz-Kleine-Straße 18 33154 Salzkotten Germany Phone: ++49 (0) 5258 / 9834 - 0 Fax: ++49 (0) 5258 / 9834 - 90 Email: info@mueller-elektronik.de...
-
Page 3: Table Of Contents
Table of contents Table of contents Product description Using the joystick Meaning of the LED lights Information on the nameplate EG declaration of conformity Assembly instructions Operation Assigning functions Executing functions Viewing functions Technical specifications Technical specifications of the joystick Pin assignment CPC connector Disposal List of accessories... -
Page 4: Product Description
ISOBUS In-Cab- Level switch Connector The ISOBUS-Joystick PRO is an ancillary operating device which can rapidly access the functions of an ISOBUS job computer. The joystick is fitted with nine buttons and a single level switch, which enables switching between two levels. -
Page 5: Information On The Nameplate
Product description Information on the nameplate Green LED light Yellow LED light Red LED light Light Meaning The connection between joystick and vehicle is active. The joystick is connected to the terminal successfully. The red level of the joystick is active. If this LED does not light up, the blue level is active. -
Page 6: Eg Declaration Of Conformity
Product description EG declaration of conformity EG declaration of conformity Herewith we declare that the product designated below, on the basis of its design and construction in the form brought onto the market by us, is in accordance with the relevant safety and health requirements of the EC Directive of Electromagnetic Compatibility 2014/30/EU. -
Page 7: Assembly Instructions
Assembly instructions Assembly instructions Procedure You fit the joystick as follows: 1. Fit the joystick next to the driver on the in the vehicle cab. Use the supplied bracket. 2. Plug the connector into the ISOBUS in-cab-connector of your vehicle. ⇨... -
Page 8: Operation
Operation Assigning functions Operation Assigning functions You assign ISOBUS job computer functions using the terminal. You can read how to do this in the operating instructions for the terminal. Executing functions Each button on the joystick can be assigned with two functions. The position of level switch determines the function which is performed when the button is pressed. - Page 9 Operation Viewing functions ⇨ You can then see which joystick button has been assigned to an ISOBUS job computer function. The current level is also shown on the screen. V2.20170628...
-
Page 10: Technical Specifications
Technical specifications Technical specifications of the joystick Technical specifications Technical specifications of the joystick Operating voltage 8 V to 32 V Temperature range -40°C to +85°C Maximum current consumption 100 mA Pin assignment CPC connector Signal Signal 12 VE CAN_L 12 VE CAN_L CAN_H... -
Page 11: List Of Accessories
List of accessories List of accessories Item number Designation 31322594 Y adapter cable with CPC and Sub-D connection 3032257801 CPC multiple socket to connect up to four operating devices V2.20170628...
