Figure 8. System wiring diagram for 4-wire duct smoke detectors:
Do not loop wire under terminals when wiring detectors. Break wire runs to provide system supervision of connections.
+
Figure 9. Wiring diagram for DH100ACDCLP
to APA451:
DH100ACDCLP
Alarm Signal 15
Aux. Power + 19
Sup. N. O. 14
Sup. COM
3
Aux. Power – 20
NOTE: Wiring diagram shown is for DH100ACDCLP 4-wire duct
smoke detector system equipped without a control panel.
NOTE: A trouble condition is indicated when the green LED
is not illuminated.
Figure 11. Multiple fan shutdown (interconnect):
1 6 A B C
12 16
DETECTOR 1
SYSTEM
FAN
CONTROL
CONTROL POWER OR
THERMOSTAT
D200-14-00
APA451
2 Alarm
(Red LED)
Power
3
(Green LED)
Common
1
H0157-00
1 6 A B C
12 16
10 DETECTORS
DETECTOR 2
SYSTEM
FAN CONTROL
CONTROL
POWER OR
THERMOSTAT
CAUTION
Figure 10. Wiring diagram for DH100ACDCLP to
RTS451/RTS451KEY:
DH100ACDCLP
Alarm Signal
Aux. Power +
Sup. N. O.
Sup. COM
Aux. Power –
Reset
Test
1 6
OUT TO
12
16
MAXIMUM
DETECTOR 10
SYSTEM
FAN CONTROL
CONTROL POWER OR
THERMOSTAT
H0155-01
6
RTS451/RTS451KEY
(Red LED) Alarm
15 1
19
*
For RTS451KEY
only without a
14
control panel.
(Green LED)
3 6
Power
20
2
2
3
4
5
11
Important Interconnect Notes
• When using the interconnect feature, all
A B C
interconnected units must be powered
with the same, independent supply.
• Polarity must be maintained throughout
the interconnect wiring. Connect termi-
nal 12 on unit 1 to terminal 12 on unit 2
and so on. Similarly, connect terminal 1
on unit 1 to terminal 1 on unit 2 and so
on.
• Up to 10 units may be interconnected.
H0158-01
*
H0156-00
I56-0084-009R
