Lindy 38156 User Manual

6 port multi av to hdmi 2.0 18g processor switch with pip
Hide thumbs Also See for 38156:
Table of Contents

Advertisement

Quick Links

Download this manual
All manuals and user guides at all-guides.com
6 Port Multi AV to HDMI 2.0 18G
Processor Switch with PiP
User Manual
Eng lis h
No. 38156
lindy.com
Tested to Comply with
FCC Standards
For Home and Office Use!
© LINDY Group - FIRST EDITION
(January 2018)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 38156 and is the answer not in the manual?

Questions and answers

Related Manuals for Lindy 38156

Summary of Contents for Lindy 38156

  • Page 1 All manuals and user guides at all-guides.com 6 Port Multi AV to HDMI 2.0 18G Processor Switch with PiP User Manual Eng lis h No. 38156 lindy.com Tested to Comply with FCC Standards For Home and Office Use! © LINDY Group - FIRST EDITION (January 2018)

  • Page 2: Package Contents

    English Introduction Thank you for purchasing the Lindy 6 Port Multi AV to HDMI 2.0 18G Processor Switch. This product has been designed to provide trouble free, reliable operation. It benefits from both a LINDY 2 year warranty and free lifetime technical support. To ensure correct use, please read this manual carefully and retain it for future reference.

  • Page 3: Rack Mount Installation

    All manuals and user guides at all-guides.com User Manual English Installation Make sure all devices are switched off before making any connections! Connect the source devices to the processor switch input ports. 4 HDMI ports, 1 DisplayPort and 1 VGA port is provided.
  • Page 4 All manuals and user guides at all-guides.com User Manual English Front Panel Operation HDMI4 INPUT PANEL STANDBY HDMI1 HDMI2 HDMI3 SWAP LOCK INPUT LAYOUT Feature Description Receives signals from the remote control IR Receiver transmitter Press to select the HDMI 1 input in full screen HDMI1 Press to select HDMI 1 audio in multi-view screen...
  • Page 5 All manuals and user guides at all-guides.com User Manual English Rear Panel Operation OUTPUT INPUT HDMI RS232 12V DC HDMI1 HDMI2 HDMI3 HDMI4 ETHERNET POWER AUDIO AUDIO ON/OFF Feature Description Connect to the DP display device, video fellows window A. OUTPUT Connect to the HDMI display device, connector on HDMI...

  • Page 6: Ir Remote Control

    All manuals and user guides at all-guides.com User Manual English IR Remote Control Feature Description Press to set system into standby mode or wake Standby up the system Lock Press to Lock or unlock the front panel buttons Select HDMI 1 in full screen mode Select HDMI 1 audio in multiview mode Select HDMI 2 in full screen mode Select HDMI 2 audio in multiview mode.
  • Page 7 All manuals and user guides at all-guides.com User Manual English Feature Description Select the Layout A (full screen mode) Select the Layout B Select the Layout C Layout* Select the Layout D Select the Layout E Select the Layout F Toggle the Input source in Layout B, C, D, E Input Swap* and F mode...
  • Page 8 All manuals and user guides at all-guides.com User Manual English Video Layout Modes Layout A – The single selected input will be displayed. This is a full screen output Layout B – The Inputs selected will be displayed in a 2 x 2 grid. Layout C –...
  • Page 9 All manuals and user guides at all-guides.com User Manual English Web GUI Please note that the unit uses the following IP settings by default, ensure that the device you are using to access the web GUI is on the same network with a compatible IP range. ...
  • Page 10 All manuals and user guides at all-guides.com User Manual English Feature Description Select output resolution 1: Auto (default) 2: 3840x2160@60Hz 3: 3840x2160@50Hz 4: 3840x2160@30Hz Resolution 5: 1920x1080@60Hz 6: 1280x720@60Hz 7: 480p@60Hz Press “Confirm” after setting to finish or press “Cancel” to ignore the modification. Output Setting Select audio output source...
  • Page 11 All manuals and user guides at all-guides.com User Manual English Feature Description Select display layout type on monitor 1: Layout A (default, full screen) 2: Layout B 3: Layout C Pre-defined* 4: Layout D 5: Layout E 6: Layout F Press “Confirm”...
  • Page 12 All manuals and user guides at all-guides.com User Manual English Feature Description Select display custom layout type on Layout monitor Setting Custom * Press “Confirm” after setting to finish or press “Cancel” to ignore the modification. Window Information in upper left side of the window.
  • Page 13 All manuals and user guides at all-guides.com User Manual English Factory Reset / Web GUI Press the “Load Default” icon to reset to the default settings for the Web UI.
  • Page 14 All manuals and user guides at all-guides.com User Manual English Serial / TELNET Commands and settings Serial Port Settings: Baud rate: 115200 Data bits: 8 Stop bits: 1 Parity: None Flow control: None Commands: Command Description Parameter SPOW 0/1 SET THE UNIT POWER ON/OFF 0=OFF,1=ON RPOW SHOW CURRENT POWER STATE...
  • Page 15 All manuals and user guides at all-guides.com User Manual English Command Description Parameter SHOW WINDOW HORIZONTAL SIZE CURRENT VALUE RHSIZE WINDOW A~D=WINDOW 1~4 HORIZONTAL SIZE 1~60 WINDOW N=1~4, 1: A, 2: B, 3: C, 4: D SVSIZE N M SET IMAGE VERTICAL SIZE VERTICAL SIZE M=1~60 SHOW WINDOW VERTICAL SIZE CURRENT VALUE...
  • Page 16 All manuals and user guides at all-guides.com User Manual English Command Description Parameter RIPM SHOW CURRENT IP MODE N=0~255, M=0~255, SIPADD N M X Y SET STATIC IP ADDRESS X=0~255, Y=0~255 RIPADD SHOW STATIC CURRENT IP ADDRESS SMAADD N M X N=0~255, M=0~255, SET STATIC SUBNET ADDRESS X=0~255, Y=0~255...

  • Page 17: Appendix 1: Function Na List

    All manuals and user guides at all-guides.com User Manual English  Appendix 1: Function NA list Input Custom Layout A Layout B Layout C Layout D Layout E Layout F Resolution Layout Rotate NA Rotate NA Rotate NA Rotate NA Rotate NA Rotate NA Rotate NA...
