- Page 1 QUICK REFERENCE GUIDE LED LCD TV Please read this manual carefully before operating your set and retain it for future reference. 32LT560H 37LT560H 42LT560H www.lg.com P/NO : MFL67415409 (1301-REV02)
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your product. Read these instructions. Keep these instructions. WARNING/CAUTION Heed all warnings. Follow all instructions. RISK OF ELECTRIC SHOCK DO NOT OPEN Do not use this apparatus near water. - Page 3 IMPORTANT SAFETY INSTRUCTIONS Protect the power cord from being walked on CAUTION concerning the Power Cord or pinched particularly at plugs, convenience (Can differ by country): receptacles, and the point where they exit It is recommended that appliances be from the apparatus. placed upon a dedicated circuit;...
- Page 4 If you smell smoke or other odors coming any way without written authorization from from the TV, unplug the power cord and LG Electronics. Unauthorized modification contact an authorized service center. could void the user’s authority to operate this Keep the product away from direct sunlight product.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS DISPOSAL (Hg lamp only used in LCD TVs) Dot Defect The Plasma or LCD panel is a high technology The fluorescent lamp used in this product contains product with resolution of two million to six a small amount of mercury. Do not dispose of this million pixels.
-
Page 6: Licenses
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com. -
Page 7: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS LICENSES OPEN SOURCE SOFTWARE NOTICE TABLE OF CONTENTS INSTALLATION PROCEDURE ASSEMBLING AND PREPARING Unpacking Parts and buttons Setting up the TV - Attaching the stand - Mounting on a table - Mounting on a wall - Tidying cables REMOTE CONTROL GENERAL TROUBLESHOOTING... -
Page 8: Installation Procedure
INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING INSTALLATION PROCEDURE Open the package and make sure all the accessories are included. Attach the stand to the TV set. Connect an external device to the TV set. ASSEMBLING AND PREPARING Unpacking Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. - Page 9 ASSEMBLING AND PREPARING ENERGY AV MODE INPUT SAVING FLASHBK LIST MARK MUTE MENU INFO Q.MENU ENTER BACK EXIT L/R SELECT FREEZE RATIO Remote Control, Quick Reference Guide Power Cord Batteries (AAA) (See p.15) Stand Body, Stand Base Stand Screws Desk-Mount Screw (See p.11) 8 EA, M4 x 14 (See p.12)
-
Page 10: Parts And Buttons
ASSEMBLING AND PREPARING Parts and buttons Remote Control Power Indicator Side Connection Panel Screen Input HDMI Input Buttons Speakers RGB IN (PC) AV IN RS-232C IN Rear Connection (CONTROL & SERVICE) / DVI IN Panel ANTENNA CABLE AUDIO IN (RGB DVI) Button Description Scrolls through the saved channels. -
Page 11: Setting Up The Tv
ASSEMBLING AND PREPARING Setting up the TV Put your TV on a pedestal stand and mount the TV on a table or wall. Attaching the stand If you are not mounting the TV to a wall, use the following instructions to attach the stand. 4 EA M4 x 14 Stand Body... -
Page 12: Mounting On A Table
ASSEMBLING AND PREPARING Mounting on a table Securing the TV to a table Lift and tilt the TV into its upright position on a Fix the TV to a table to prevent from tilting table. forward, damage, and potential injury. To secure the TV to a table, insert and tighten the - Leave a 10 cm (minimum) space from the supplied screw on the rear of the stand. -
Page 13: Mounting On A Wall
When you attach the TV to other building wall, it may fall and result in severe injury. materials, please contact qualified personnel. Use an authorized LG wall mount and contact LG recommends that wall mounting be performed the local dealer or qualified personnel. -
Page 14: Tidying Cables
ASSEMBLING AND PREPARING Tidying cables Securing the TV to a wall (optional) (Depending on model) Install the power cord holder and power cord. It will help prevent the power cable from being removed by accident. Power Cord Holder Gather and bind the cables with the cable holder. -
Page 15: Remote Control
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching the ends to the label inside the compartment, and close the battery cover. - Page 16 REMOTE CONTROL Q.VIEW LIST Adjusts the volume level. PORTAL FAV / MARK FAV: Accesses your favorite channel list. MUTE MARK: Selects a menu or option. PORTAL GUIDE Q.MENU SETTINGS Displays and removes the hotel interactive menu. MUTE Mutes all sounds. Scrolls through the saved channels.
-
Page 17: General Troubleshooting
GENERAL TROUBLESHOOTING GENERAL TROUBLESHOOTING Installation Symptom Possible Cause(s) Possible Solution(s) Cannot direct enter (TV in Pass-through Mode) Installer If the channel lineup is locked, only channels channel number. Menu item 028 CH. OVERIDE is set that are active in the TV’s channel lineup can to 0, i.e., disabled (recommended be selected. - Page 18 Check that “+” and “-” match in battery compartment. Too much light in room. Dim room light. Wrong Installer Remote. Requires compatible Installer Remote. Contact your LG dealer. Bed Switch set to wrong bed. Set Bed Switch or update Installer Menu, as necessary.
-
Page 19: Specifications
Temperature Operating Humidity Less than 80% Storage Temperature -20 - 60°C Storage Humidity Less than 85% 32LT560H 37LT560H MODELS (32LT560H-SA) (37LT560H-SA) Dimensions With stand 765.6 mm x 535.6 mm x 231.9 mm 867.3 mm x 592.8 mm x 231.9 mm... - Page 20 SPECIFICATIONS RGB(PC), HDMI (PC) supported mode Horizontal Vertical Resolution Frequency (KHz) Frequency (Hz) 720x400 31.469 70.08 640x350 31.46 70.07 640x480 31.469 59.94 800x600 37.879 60.31 1024x768 48.363 60.00 1152x864 54.34 60.05 1360x768 47.712 60.015 1280x1024 63.981 60.020 For 37/42LT560H 1920x1080 67.5 60.00 HDMI (DTV) supported mode...
-
Page 21: Ir Codes
IR CODES IR CODES (Depending on model) Code Code Function Note Function Note (Hexa) (Hexa) POWER Remote control Button Remote control Button (Power On/Off) Remote control Button Q.MENU Remote control Button EXIT Remote control Button SETTINGS or MENU Remote control Button PORTAL Remote control Button INPUT... -
Page 22: External Control Device Setup
EXTERNAL CONTROL DEVICE SETUP EXTERNAL CONTROL DEVICE SETUP RS-232C Setup Type of connector; D-Sub 9-Pin Male Connect the RS-232C (serial port) input jack to an external control device (such as a computer or an A/V control system) to control the product’s functions externally. -
Page 23: Rs-232C Configurations
EXTERNAL CONTROL DEVICE SETUP RS-232C configurations Set ID Set ID number. 4-Wire Configuration (Serial female-female NULL modem cable) OPTION ꔂ Move ꔉ OK • Language • Caption : Off • Standby Light : On • My Media Setting +3.5V +3.5V •... -
Page 24: Communication Parameters
EXTERNAL CONTROL DEVICE SETUP Communication Parameters Baud rate: 9600 bps (UART) Stop bit: 1 bit Data length: 8 bits Communication code: ASCII code Parity : None Use a crossed (reverse) cable. Command reference list DATA DATA COMMAND1 COMMAND2 COMMAND1 COMMAND2 (Hexadecimal) (Hexadecimal) 01. -
Page 25: Transmission / Receiving Protocol
EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the set.(j, k, m or x) [Command 2] : Second command to control the set. [Set ID] : You can adjust the set ID to choose desired set ID number in Option menu. Adjustment range is 1~ 99. - Page 26 EXTERNAL CONTROL DEVICE SETUP 01. Power (Command: k a) 06. Volume Control (Command: k f) To control Power On/Off of the set. To adjust volume. You can also adjust volume with the volume buttons on Transmission [k][a][ ][Set ID][ ][Data][Cr] remote control.
- Page 27 EXTERNAL CONTROL DEVICE SETUP 12. OSD Select (Command: k l) *If data01 is 00(3D On), data04 has no meaning. To select OSD (On Screen Display) on/off. *If data01 is 01(3D Off) or 02(3D to 2D), data02, data03 Transmission [k][l][ ][Set ID][ ][Data][Cr] and data04 have no meaning.
- Page 28 EXTERNAL CONTROL DEVICE SETUP 20. Energy Saving (Command: j q) * Tune Command Examples: 1. Tune to the analog (NTSC) cable channel 35. To control the energy saving function. Data 00 = Physical of 35 = 23 Transmission [ j ][q][ ][Set ID][ ][Data][Cr] Data 01 &...
- Page 29 EXTERNAL CONTROL DEVICE SETUP * Table List (Channel Tuning) Two/One Using Main/Sub Part Physical Step Picture Reserved Channel Channel Main NTSC Air No Use NTSC Cable ATSC Air ATSC Cable_std ATSC Cable_hrc ATSC Cable_irc ATSC cable_auto Reserved Reserved...
- Page 30 The model and serial numbers of the TV are located on the back and/or one side of the TV. Record them below should you ever need service. MODEL SERIAL...
