Arbor Technology Tokin Series User Manual

Fanless industrial panel pc with intel celeron 827e / atom d2550
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TOKIN Series
Fanless Industrial Panel PC
with
®
®
Intel
Celeron
827E / Atom™ D2550
User's Manual
Version 1.1
2014.02
P/N: 4010608300110P
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tokin Series and is the answer not in the manual?

Questions and answers

Related Manuals for Arbor Technology Tokin Series

Summary of Contents for Arbor Technology Tokin Series

  • Page 1 TOKIN Series Fanless Industrial Panel PC with ® ® Intel Celeron 827E / Atom™ D2550 User’s Manual Version 1.1 2014.02 P/N: 4010608300110P...
  • Page 2 This page is intentionally left blank. - 2 -...
  • Page 3 Revision History Version Date Description October 2012 Initial release This revision is issued due to the following change in this user’s manual: February 2014 ► 3.6. Wire DC-Input Power Source ► Combine Celeron and Atom models into one manual - i -...
  • Page 4 This page is intentionally left blank. - ii -...

  • Page 5: Table Of Contents

    Contents Contents Revision History .................... i Contents ....................... iii Preface......................v Chapter 1 - General Information ..............1 1.1. Introduction .................. 2 1.2. Packing List .................. 2 1.3. Ordering Information ..............3 1.4. CD Driver Paths ................4 1.5. Specifications ................6 1.6.

  • Page 6: Contents

    Contents Chapter 5 - BIOS ..................69 5.1. Main ..................... 72 5.2. Advanced ..................74 5.2.1. ACPI Settings..............75 5.2.2. CPU Configuration ............76 5.2.3. SATA Configuration ............76 5.2.4. USB Configuration ............76 5.2.5. H/W Monitor ..............77 5.2.6. Super IO Configuration ..........77 5.2.7.

  • Page 7: Preface

    Preface Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such...
  • Page 8 (PBDE) in electrical and electronic products. Member states of the EU are to enforce by 7/1/2006. ARBOR Technology Corp. hereby states that the listed products do not contain unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed a maximum concentration value of 0.1% by weight or for cadmium exceed...
  • Page 9 Preface 6. The openings on the enclosure are for air convection and protect the equipment from overheating. DO NOT COVER THE OPENINGS. 7. Position the power cord so that people cannot step on it. Do not place anything over the power cord. 8.
  • Page 10 Preface Technical Support If you have any technical difficulties, please consult the user’s manual first at: ftp://ftp.arbor.com.tw/pub/manual Please do not hesitate to call or e-mail our customer service when you still cannot find out the answer. http://www.arbor.com.tw E-mail:info@arbor.com.tw Warranty This product is warranted to be in good working order for a period of one year from the date of purchase.

  • Page 11: Chapter 1 - General Information

    Chapter 1 General Information Chapter 1 - General Information - 1 -...

  • Page 12: Introduction

    Carefully inspect the contents in the package, which should contain the items listed hereunder. If any item is missing or appears damaged, contact your local dealer or distributor. TOKIN-6083 TOKIN-6123 TOKIN-6153 1 x TOKIN series Industrial Panel PC (TOKIN-6083, TOKIN-6123 or TO- KIN-6153) 1 x Accessory Box that contains the following items: •...

  • Page 13: Ordering Information

    General Information 1.3. Ordering Information TOKIN-6083-827E 8” Intel ® Celeron ® 827E industrial panel PC ® ® TOKIN-6123-827E 12” Intel Celeron 827E industrial panel PC ® ® TOKIN-6153-827E 15” Intel Celeron 827E industrial panel PC TOKIN-6083-D2550 8” Intel® Atom™ D2550 industrial panel PC TOKIN-6123-D2550 12”...

  • Page 14: Cd Driver Paths

    General Information 1.4. CD Driver Paths Find the drivers on CD for each Windows XP and Windows 7 operating system. ® ® For Models with Intel Celeron 827E processor : Windows XP Driver & AP Path Chipset \Chipset Framework 3.5 \NET Framework 3.5 \Graphic\WinXP\x64 \Graphic\WinXP\x86...
  • Page 15 General Information ® ™ For Models with Intel Atom D2550 processor : Windows XP Driver & AP Path \CHIPSET\Win_x86 Chipset \CHIPSET\Win_x64 .NET Framework 3.5 \NET Framework 3.5 \GRAPHIC\WIN XP\Utilities \LAN\WinXP \TOUCH\PenMount Windows Universal Driver V2.2.0.283. Touch (Win7_32_64bit_WHQL) AHCI \AHCI Windows 7 Driver &...

  • Page 16: Specifications

    General Information 1.5. Specifications System Kernel 827E 1.4GHz processor ® ® Intel Celeron Processor D2550 1.86GHz processor ® ™ Intel Atom ® ® ® Intel HM65 for Intel Celeron 827E Chipset ® ® ™ Intel PCH NM10 for Intel Atom D2550 2 x DDR3 SO-DIMM Sockets, supporting 1333/1066 MHz SDRAM up to 8GB...
  • Page 17 General Information Panel-mounting chassis, Aluminum Front Bezel and SECC Chassis steel chassis 274.96 x 77.0 x 207.96 mm (10.82” x 3.03” x 8.18”) for TOKIN-6083 325.86 x 77.0 x 258.86 mm (12.82” x 3.03” x 10.18”) for Dimension TOKIN-6123 (W x D x H) 389.93 x 84.3 x 309.93 mm (15.35”...

  • Page 18: Locating Controls And Connectors

    General Information 1.6. Locating Controls and Connectors Front View of TOKIN-6153 Power on LED Brightness down Screen on/off Brightness up Front View of TOKIN-6123 - 8 -...
  • Page 19 General Information Front View of TOKIN-6083 Rear View of TOKIN-6153 - 9 -...
  • Page 20 General Information Rear View of TOKIN-6123 Rear View of TOKIN-6083 - 10 -...
  • Page 21 General Information Bottom View of TOKIN-6153 DVI-I DC-IN COM Ports Power Switch Expansion Bus Optional Port (D-sub Type) Bottom View of TOKIN-6123 Bottom View of TOKIN-6083 - 11 -...

  • Page 22: Dimensions

    General Information 1.7. Dimensions TOKIN-6153 - 12 -...
  • Page 23 General Information TOKIN-6123 - 13 -...
  • Page 24 General Information TOKIN-6083 - 14 -...
  • Page 25 This page is intentionally left blank. - 15 -...

  • Page 26: Chapter 2 - Engine Of The Ippc

    Chapter 2 Engine of the IPPC Chapter 2 - Engine of the IPPC - 16 -...

  • Page 27: Board Layout

    Engine of the IPPC 2.1. Board Layout The engine of TOKIN industrial panel PC is constructed with the carrier board PBC-9005P and SCDB-1443 (the CFast board). RSTB1 JPIC1 JATX1 USB5 JVLCD1 LAN1 LAN2 JBAT1 PCIE1 PCI1 SATA 1/2 FAN1 DGP1 - 17 -...

  • Page 28: Jumpers And Connectors

    Engine of the IPPC 2.2. Jumpers and Connectors 2.2.1. Jumpers & Connectors List Jumpers Label Function JBAT1 CMOS Jumper Setting JATX1 AT/ATX Mode Selector JVLCD1 LVDS VCC Selector RS232/485 Mode Switch Connectors Label Function JPIC1 PIC Programming Pin Header USB5 USB KEY PRO Pin Header Buzzer Pin Header DGP1...

  • Page 29: Jumper Settings

    Engine of the IPPC 2.2.2. Jumper Settings • JBAT1: Clears CMOS Setting Connector Type: onboard 1 x 3-pin 2.54mm pin-header Pin Description 1-2 Keeps CMOS (default) 2-3 Clears CMOS • JATX1: AT/ATX Mode Selector Connector Type: onboard 1 x 3-pin 2.00mm pin-header Pin Description 1-2 AT Mode 2-3 ATX Mode (default)

  • Page 30: Dip Switch Settings

    Engine of the IPPC 2.2.3. DIP Switch Settings The computer’s carrier board comes with a 6-toggle DIP switch SW3 to configure the data transmitting interfaces for serial ports COM1 and COM2. Follow the guide below to configure COM1 and COM2 between RS-232 and RS-485 (with or without terminator): 1.

  • Page 31: Connector Pin Assignments

    Engine of the IPPC 2.2.4. Connector Pin Assignments • JPIC1: External PIC Programming Pin Header Connector Type: onboard 2.0mm pitch 2 x 3-pin headers Pin Description Pin Description PIC_TX ICSP-CLK ICSP-DAT VCC5 MCU_RST • USB5: USB KEY PRO Pin Header Connector Type: onboard 2.54mmmm pitch 4-pin header Pin Description Pin Description...
  • Page 32 Engine of the IPPC • RSTB1: Reset Button Pin Header Connector Type: onboard 2.54mm pitch 4-pin headers Pin Description Pin Description SYS_RESET# PWR_IN_SW# • FAN1: Fan Connector Connector Type: onboard 3-pin wafer connector Pin Description 1 2 3 +12V • COM1 &COM2: Serial port DB9 connectors Connector Type: External 9-pin D-sub male connectors Pin Description...
  • Page 33 This page is intentionally left blank. - 23 -...

  • Page 34: Chapter 3 - Installation And Maintenance

    Chapter 3 Installation and Maintenance Chapter 3 - Installation and Maintenance - 24 -...

  • Page 35: Install Ssd, Pcie, Pci And Mini-Card

    Installation and Maintenance 3.1. Install SSD, PCIe, PCI and Mini-card The TOKIN industrial panel PC is based upon modular design for easier maintenance. This section will cover the simple hardware installations for the IPPC. Make sure the IPPC is powered off before any action is taken. 3.1.1.

  • Page 36: Install Ssd

    Installation and Maintenance 3.1.2. Install SSD 1. Remove the computer’s rear panel as described in 3.1.1. Remove the Rear Panel on page 25. Loosen and remove the four screws at the left and bottom sides. Gently dismount the left panel. - 26 -...
  • Page 37 Installation and Maintenance Loosen and remove the screw that fixes the SSD bracket. Then remove the bracket. Attach the SSD to the bracket and fix them together by using screws at the four corners. - 27 -...
  • Page 38 Installation and Maintenance Restore the bracket (with the SSD) and fix them in place. The SSD barcket is one of the standard accessories included in the accessory box. This SSD bracket can be replaced by an additional CFast socket bracket. - 28 -...

  • Page 39: Install Pci Card

    Installation and Maintenance 3.1.3. Install PCI Card Loosen and remove the screw as marked in the picture below. Carefully dismount the bracket. 2. Insert your desired PCI card into the slot and fix it in place. - 29 -...

  • Page 40: Install Pcie Card

    Installation and Maintenance 3.1.4. Install PCIe Card 1. The PCI slot can be replaced with the PCIe slot included in the accessory kit. Loosen and remove the two screws that fixes the PCI slot first of all. Carefully remove the PCI slot and insert the PCIe slot in place. - 30 -...

  • Page 41: Install Mini-Card

    Installation and Maintenance 2. Insert your desired PCIe x 1 card into the slot and fasten it. 3.1.5. Install Mini-card 1. Locate the Mini-card socket. 2. Plug a Bluetooth or HSUPA module to the socket's connector by a slanted angle. Note the notch on the card should meet the break on the connector. 3.

  • Page 42: Install/Uninstall Cfast Card

    Installation and Maintenance 3.2. Install/Uninstall CFast Card If the OS is installed on the CFast card, power off the IPPC before proceeding with the uninstallation of CFast Card. 1. See the picture below. Loosen and remove the screw. Dismount the CFast card door.
  • Page 43 Installation and Maintenance 2. Insert your CFast card into either of the slots as the pictures below show. 3. If later it is needed to remove the CFast card, simply remove the card door and push-eject the CFast card. - 33 -...

  • Page 44: Install Internal Usb Drive

    Installation and Maintenance 3.3. Install Internal USB Drive As some critical application programs rely on USB keys to run, an USB drive is therefore necessary to store the related encrypted keys and digital certificates. The TOKIN-Series IPPC supports an USB drive to work inside the chasis to deliver extrodinary protection against any unauthorized tamper to the USB drive from the outside.
  • Page 45 Installation and Maintenance 3. Detach the internal USB bracket from the carrier board. Detach the internal USB bracket. pin connector bumper rubber for USB Drive USB port Take a look at the detached USB bracket. 4. Install an USB drive to the USB bracket. - 35 -...
  • Page 46 Installation and Maintenance 5. To reinforce the installation of the USB drive, slide the bumper rubber to the installed USB drive by loosening and relocating the bolt as displayed in the picture below. bumper rubber bolt Adjust the bumper rubber to the USB drive. 6.

  • Page 47: Panel Mounting

    Installation and Maintenance 7. Restore the rear panel to the IPPC. 3.4. Panel Mounting There are two approaches to mount the IPPC to a panel - by either clamps or brackets. The following sections will walk your through these two approaches. 3.4.1.

  • Page 48: Panel Mounting With Brackets

    Installation and Maintenance 3.4.2. Panel Mounting with Brackets Before you proceed, make sure the panel to mount is no thicker than 4mm. The panel to mount must be no thicker than 4mm. Then follow the steps below to mount the IPPC to a panel using brackets: 1.
  • Page 49 Installation and Maintenance 2. Assemble the brackets to each side. Fasten the screws. 3. Fine-tune the mounting firmness by adjusting bolts tightness. - 39 -...

  • Page 50: Vesa Arm Mounting

    Installation and Maintenance 3.5. VESA Arm Mounting The TOKIN-Series supports VESA arm mounting of 75 x 75mm or 100 x 100mm mounting hole pattern. See the illustration below for the example. 1. Have the VESA arm and the four mounting screws that come with it. 2.

  • Page 51: Wire Dc-Input Power Source

    Installation and Maintenance 3.6. Wire DC-Input Power Source Only trained and qualified personnel are allowed to install Warning or replace this equipment. Follow the instructions below for connecting the computer to a DC-input power source. 1. Before wiring, make sure the power source is disconnected. 2.
  • Page 52 Installation and Maintenance 7. Use a slotted screwdriver to tighten the captive screws. Plug the terminal block firmly, which wired, into the power receptacle at the bottom of the computer. Power Receptacle Plug the terminal block to the power receptacle. DC-IN DC-IN Terminal block with pin 3 earth-grounded.
  • Page 53 This page is intentionally left blank. - 43 -...

  • Page 54: Chapter 4 - Driver & Ap

    Chapter 4 Driver & AP Chapter 4 - Driver & AP - 44 -...

  • Page 55: Before Installation

    Driver & AP 4.1. Before Installation After everything aforementioned is done, proceed to install the necessary drivers and the application so the IPPC can function for you. The following instructions take Windows XP (x86) as the exemplary OS. Different OS may vary slightly regarding driver/AP installation, but generally they are similar.
  • Page 56 Driver & AP ® ™ For Models with Intel Atom D2550 processor : Windows XP Driver & AP Path Chipset \CHIPSET\Win_x86 \CHIPSET\Win_x64 .NET Framework 3.5 \NET Framework 3.5 \GRAPHIC\WIN XP\Utilities \LAN\WinXP \TOUCH\PenMount Windows Universal Driver V2.2.0.283.( Touch for XP Embedded)\repository AHCI \AHCI Windows 7...

  • Page 57: Drivers

    Driver & AP 4.2. Drivers 4.2.1. CHIPSET 1. Run the executable file “infinst_autol.exe” as described in 4.1. Before Installation on page 45. The installation wizard then opens and starts to extract the files required for driver installation. 2. Click Next to proceed. - 47 -...
  • Page 58 Driver & AP 3. Read the license agreement and click Yes to proceed. 4. Read the readme file and click Next to proceed. - 48 -...
  • Page 59 Driver & AP 5. The installation wizard then starts to proceed with some setup operations. Once the setup operations are through, click Next to proceed. - 49 -...
  • Page 60 Driver & AP 7. Click Finish to finish and quit the driver installation. - 50 -...

  • Page 61: Framework 3.5

    Driver & AP 4.2.2. Framework 3.5 1. Run the executable file “NET Framework 3.5.exe” at the suggested path (\ NET Framework 3.5) as described in 4.1. Before Installation on page 45. Files extraction is then triggered for the driver installation. Once the files extraction is through, the installation wizard opens.
  • Page 62 Driver & AP 3. The driver installation then starts and progresses. 4. Once the installation is through, click Exit to finish and quit the installtion. - 52 -...

  • Page 63: Vga

    Driver & AP 4.2.3. VGA For Models with Intel ® Celeron ® 827E, please refer to the following steps. 1. Run the executable file “winxp_14469.exe” at the suggested path (\Graphic\ WinXP\x86) as described in 4.1. Before Installation on page 45. The installation wizard then opens.
  • Page 64 Driver & AP 3. Once the files extraction is through, click Next to proceed. 4. Read the license agreement and click Yes to proceed. - 54 -...
  • Page 65 Driver & AP 5. Read the readme file and click Next to proceed. Setup then starts and progresses. - 55 -...
  • Page 66 Driver & AP 6. Once the setup is through, click Next to proceed. 7. Select Yes, I want to restart this computer now and click Finish. - 56 -...
  • Page 67 Driver & AP ® ™ For Models with Intel Atom D2550 processor, please refer to the following steps. 1. Run the executable file “Setup.exe” at the folder \GRAPHIC\WIN XP\ Utilities as described in 4.1. Before Installation on page 45. A dialog opens onscreen. 2.
  • Page 68 Driver & AP 3. Select I agree and click Install to proceed. The driver files then start to install on the computer. Once the installation is through, you are prompted to restart the computer to apply the change. 4. Click Yes to restart the system by the support of the newly installed graphics driver.

  • Page 69: Lan

    Driver & AP 4.2.4. LAN 1. Run the executable file “PROWin32.exe” at the suggested path as described 4.1. Before Installation on page 45. Files extraction then starts and progresses. 2. Once the files extraction is through, click Next to proceed. - 59 -...
  • Page 70 Driver & AP 3. Read the agreement. Select I accept the terms in the License agreement and click Next to proceed. 4. Select the program features to install and click Next to proceed. - 60 -...
  • Page 71 Driver & AP 5. Click Install to proceed. The driver installation then starts and progresses. - 61 -...
  • Page 72 Driver & AP 6. Once the driver installation is through, click Finish to finish and quit the installation. - 62 -...

  • Page 73: Touch

    Driver & AP 4.2.5. TOUCH 1. Run the executable file “Setup.exe” at the suggested path (\TOUCH\ PenMount Windows Universal Driver V2.2.0.283.(Win7_32_64bit_WHQL)) as described in 4.1. Before Installation on page 45. The installation wizard then opens. Click Next to proceed. 2. Read the license agreement and click I Agree to proceed. - 63 -...
  • Page 74 Driver & AP 3. Select where to install the driver. Then click Install to proceed. 4. Once the installation is through, click Finish to finish and quit the installation. - 64 -...

  • Page 75: Ahci (Advanced Host Controller Interface)

    Driver & AP 4.2.6. AHCI (Advanced Host Controller Interface) For Models with Intel ® Atom ™ D2550 processor only: 1. Run the executable file “STOR_allOS_10.6.0.1022.exe” at the folder \AHCI as described in 4.1. Before Installation on page 45. The installation wizard then opens and prepares to install the driver. 2.
  • Page 76 Driver & AP 3. Read the license agreement and click Yes to proceed. 4. Read the readme file and click Next to proceed. - 66 -...
  • Page 77 Driver & AP 5. A Setup Progress window opens. Driver installation then starts and progresses. 6. Once the installation is through, the Next button on Setup Progress window becomes available. Click Next to proceed. - 67 -...
  • Page 78 Driver & AP 7. Select Yes, I want to restart this computer now. and click Finish button to restart the system to immediately apply the change, or select No, I will restart this computer later. - 68 -...

  • Page 79: Chapter 5 - Bios

    Chapter 5 BIOS Chapter 5 - BIOS - 69 -...
  • Page 80 BIOS The BIOS SETUP utility for TOKIN-Series is featured by American Megatrends Inc to configure the system settings stored in the system’s BIOS ROM. The BIOS is activated once the IPPC powers on. When the IPPC is off, the battery on the main board supplies power to BIOS RAM.
  • Page 81 BIOS Key Commands The BIOS SETUP utility relies on a keyboard to receive user’s instructions. Hit the following keys to navigate within the utility and use it. Keystroke Function ← → Moves left/right between the top menus. ↓ ↑ Moves up/down between highlight items. Selects an highlighted item/field.

  • Page 82: Main

    BIOS 5.1. Main The Main menu features System Date and System Time settings while displaying some BIOS info. The BIOS info displayed are: Item Description BIOS Vendor Delivers the provider of the BIOS Setup utility. Core Version Delivers the version info of the core. Compliency Delivers UEFI support.
  • Page 83 BIOS ® ™ For Models with Intel Atom D2550, please refer to the following picture. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit BIOS Information Set the Date. Use Tab to BIOS Vendor American Megatrends switch between Data elements.

  • Page 84: Advanced

    BIOS 5.2. Advanced The Advanced menu configures the system’s Super IO chip. ® ® For Models with Intel Celeron 827E, please refer to the following picture. Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Legacy OpROM Support System Super IO Chip Launch PXE OpROM...

  • Page 85: Acpi Settings

    BIOS The featured settings and submenus are: Setting Description Launch PXE OpROM Enables/disables the boot option for legacy network devices. Disabled is the default. ► Launch Storage OpROM Enables/disables the boot option for legacy mass storage devices with Option ROM. Enabled is the default.

  • Page 86: Cpu Configuration

    BIOS 5.2.2. CPU Configuration Select CPU Configuration to view the CPU parameters such as the model name, processor stepping, processor speed, microcode revision, max. processor speed, min. processor speed, processor cores, Intel HT Technology and EMT64 support. 5.2.3. SATA Configuration SATA Configuration delivers SATA device(s) information and provides users with the settings to control SATA device.

  • Page 87: H/W Monitor

    BIOS 5.2.5. H/W Monitor H/W Monitor monitors the systems’ hardware status. Select H/W Monitor to run a health report of the IPPC that includes the info of CPU temperature, system temperature, VCC, VCORE and so on. 5.2.6. Super IO Configuration Super IO Configuration controls the system’s Super IO chip.
  • Page 88 BIOS The following settings are featured for the specified serial port: Serial Port 2 Configuration Setting Description Serial Port Enables/disables the serial port (COM). Enabled is the default. ► Change Sets the optimal IO address and IRQ info for Settings the Super IO device.

  • Page 89: Chipset

    BIOS 5.3. Chipset The Chipset menu controls the system’s chipset. ® ® For Models with Intel Celeron 827E, please refer to the following picture. Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit System Agent (SA) Parameters System Agent (SA) Configuration PCH-IO Configuration...

  • Page 90: System Agent (Sa) Configuration

    BIOS For Models with Intel ® Atom ™ D2550, please refer to the following picture. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Host Bridge Host Bridge Parameters South Bridge →←: Select Screen : Select Item Enter: Select...
  • Page 91 BIOS 5.3.1.1. Graphic Configuration Select Graphic Configuration to view graphics info and accesses graphic settings. The featured settings are: Setting / Description Submenu Graphics Sets the graphic turbo IMON current values. Turbo IMON Options available are 14 to 31. ► Current 31 is the default.
  • Page 92 BIOS Primary IGF Boot Display Sets the video device to activate during POST. Options available are CRT, LVDS and CRT + LVDS (default). ► This setting has no effect if an external graphics card is present. ► Secondary boot display selection will appear based on your selection. ►...
  • Page 93 BIOS Enables/disables Backlight Image Adaptation control. Options available are Auto (default), Disabled and Level 1~5. ► Select Auto to have GMCH backlight control use VBT default. ► Select Level 1~5 to enable BIA control with different aggressiveness. ► Spread Spectrum clock Chip Sets which hardware / software to control the spread spectrum.
  • Page 94 BIOS Panel Color Depth Sets the color depth for LFP panel. Options available are 18 Bit and 24 Bit. ► 5.3.1.2. DMI Configuration Use this submenu to control various DMI features. 5.3.1.3. NB PCIe Configuration Configures NB PCI Express. Featured settings are: Setting Description Configures PEG0 B0:D1:F0 Gen1-Gen2.

  • Page 95: Pch-Io Configuration

    BIOS 5.3.1.4. Memory Configuration Select Memory Configuration to view the system’s memory information that includes memory RC version, memory frequency, total memory, DIMM presence, CAS latency and minimum delay time. 5.3.2. PCH-IO Configuration PCH-IO Configuration sets PCH parameters. Featured settings are: Setting / Submenu Description PCH LAN Controller...

  • Page 96: Host Bridge

    BIOS 5.3.3. Host Bridge This submenu opens showing the memory information such as memory frequency, total memory and the memory module(s) connected. This submenu also features one submenu - Intel IGD Configuration to configure Intel IGD (Internal Graphics Device) by the following settings: Setting Description Auto Disable IGD...
  • Page 97 BIOS Sets the IGD clock to use. IGD Clock Source Options available are External Clock (default) ► and Internal Clock. Sets the fixed graphics memory size. Fixed Graphics Memory Size Options available are 128MB (default) and ► 256MB. ALS Support Enables/disables ALS (ambient light sensor) support.

  • Page 98: South Bridge

    BIOS 5.3.4. South Bridge The submenu South Bridge configures the south bridge features by the following setting and submenu: Setting / Description Submenu TPT Device ® This is a submenu to control Intel IO Controller Hub (TPT), which connects and controls peripheral devcies. The featured settings are: Setting Description...
  • Page 99 BIOS 5.3.4.1. Selecting By Ports When Select USB Mode is set to By Ports, the following setting becomes available: Setting Description USB Function Enables a certiain number of ports for USB function or disables them all. This setting is only available when Select USB ►...

  • Page 100: Boot

    BIOS 5.4. Boot The Boot menu configures how to boot up the system such as boot device priority. ® ® For Models with Intel Celeron 827E, please refer to the following picture. Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot...
  • Page 101 BIOS The featured settings are: Setting Description Bootup NumLock Sets keyboard’s NumLock state when the system State boots up. Options available are On (default) and Off. ► Quiet Boot Sets whether to display the POST (power on self tests) messages or the system manufacturer’s full screen logo during booting.

  • Page 102: Security

    BIOS 5.5. Security The Security menu sets up the administrator password. Once an administrator password is set up, this BIOS SETUP utility is limited to access and will ask for the password each time any access is attempted. ® ® For Models with Intel Celeron 827E, please refer to the following picture.
  • Page 103 BIOS The featured setting is: Setting Description Administrator To set up an administrator password: Password 1. Select Administrator Password. The screen then pops up an Create New Password dialog. 2. Enter your desired password that is no less than 3 characters and no more than 20 characters. 3.

  • Page 104: Save & Exit

    BIOS 5.6. Save & Exit The Save & Exit menu features a handful of commands to launch actions from the BIOS SETUP utility regarding saving changes, quitting the utility and recovering defaults. For Models with Intel ® Celeron ® 827E, please refer to the following picture. Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
  • Page 105 BIOS Features settings are: Setting Description Save Changes and Saves the changes and resets the system. Reset This is a command to launch action from the ► BIOS SETUP utility. Discards Changes Discards the changes and quits the BIOS SETUP and Exit utility.

  • Page 106: Appendix

    Appendix Touch Panel Appendix - 96 -...

  • Page 107: Penmount Monitor

    Appendix 1. PenMount Monitor The PenMount Monitor icon (pm) will appear in the system tray at the bottom- right corner after you turn on PenMount Monitor from Programs/ PenMount Universal Driver/PenMount Monitor. Right-click the pm icon in system tray and display its submenu. PenMount Monitor has the following functions: Control Panel Launch the PenMount Control Panel utility.

  • Page 108: Penmount Control Panel

    Appendix 2. PenMount Control Panel After you have selected the Control Panel item on the pop-up menu or open it up from Programs (as shown on previous page), the PenMount Control Panel utility UI appears as below. The functions of the PenMount Control Panel such as Device, Calibrate, Setting, Multiple Monitors, Tools and About are explained in the following sections.
  • Page 109 Appendix Draw Tests or demonstrates the PenMount touch screen operation. Advanced Calibration Enable Advanced Calibration function. Right Button Icon Enable right button function. The icon can be shown on Desktop or in the system tray at the bottom-right corner. - 99 -...
  • Page 110 Appendix The Device Tab In this window, you can find out how many devices are detected on your system. On the Device tab, select the device icon and tap Configure, or double tap the device icon for touch screen calibration. And then another window with the Calibrate tab appears.
  • Page 111 Appendix 1. Please tap the Standard Calibration button to start calibration procedures. 2. After tapping the button, the arrow appears pointing to a red square. Use your finger or stylus to touch the red square and hold down until the screen shows the message - "Lift off to proceed".
  • Page 112 Appendix Note: The older the touch screen gets, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for better accuracy. Please follow the step as below: Advanced Calibration The Advanced Calibration function improves the accuracy of calibration by using more involved engineering calculations.
  • Page 113 Appendix 2. Select Device to calibrate, and then you can start to do "Advanced Calibration". Tap the arrow to pull down the drop-down menu and select the number determining how many points will be used for calibration. Note: You are recommended to use a stylus during Advanced Calibration for greater accuracy.
  • Page 114 Appendix Plot Calibration Data Check this function to have touch panel linearity comparison graph appear when you finish Advanced Calibration. The black lines reflect the ideal linear- ity assumed by PenMount's application program while the blue lines show the approximate linearity calculated by PenMount's application program as the result of user’s execution of Advance Calibration.
  • Page 115 Appendix Beep Sound Turn On/Off Beep Sound. Beep on Pen Beep occurs when pen is down. Down Beep on Pen Up Beep occurs when pen is up. Beep on Both Beep occurs when pen is down or up. Modifies sound frequency. Beep Frequency Modifies sound duration.
  • Page 116 This page is intentionally left blank. - 106 -...
