Quick Set-Up Guide – Central and Adjustable Side Lighting Iris Camera
MEC-5-CASL-D3200-N85
A. Contents of the Camera Carry Case – MEC-5-CASL-D3200-N85
Quick Setup Guide for MEC-5-CASL-D3200-N85
Contents
1. Camera with macro lens
2. Illuminator
3. Alignment Target w/Protractor
4. Zoom Lens
5. Camera Battery Charger
6. Cord Compartment
6a. Camera batteries
6b. Camera USB cord
6c. Camera A/V cord
6d. SDHC memory card (16GB)
6e. USB Card Reader w/cord
6f. Lens rear cap/body cap
6g. Spare batteries (focus light)
6h. #0 screwdriver (for battery case)
1
Advertisement
Table of Contents
Related Manuals for Miles Research MEC-5-CASL-D3200-N85
Summary of Contents for Miles Research MEC-5-CASL-D3200-N85
- Page 1 Quick Set-Up Guide – Central and Adjustable Side Lighting Iris Camera MEC-5-CASL-D3200-N85 A. Contents of the Camera Carry Case – MEC-5-CASL-D3200-N85 Contents 1. Camera with macro lens 2. Illuminator 3. Alignment Target w/Protractor 4. Zoom Lens 5. Camera Battery Charger 6.
- Page 2 B. Preparing the Iris Camera for Use – MEC-5-CASL-D3200-N85 1. Open Camera Carry Case by pressing the button and lifting up each latch. 2. Remove the camera from the foam padding and set down. 3.Lift Illuminator out of foam-padded case...
- Page 3 5. Be sure Mode dial is set to A=Aperture priority 6. Pop up the built-in flash by pressing button on left side 7. Place illuminator onto lens at the 9:00 position (Flash is in the up position, Mode=A): Quick Setup Guide for MEC-5-CASL-D3200-N85...
- Page 4 8. Rotate Illuminator 90 degrees until it snaps into place at 12:00 position: 9. Rotate focus light power control clockwise to switch it on: Quick Setup Guide for MEC-5-CASL-D3200-N85...
- Page 5 This is where the illuminator sliding shutter is in the center position: For more info on operating the lightguide shutter and setting the angle of illumination, see the User Guide for Miles Eye Camera MEC-5-CASL-D3200-N85. Quick Setup Guide for MEC-5-CASL-D3200-N85...
- Page 6 Also have a spare set of AAAx3 batteries on hand for the Focus Light. 13. Alternate Power for focus light: The focus light can also be powered by using the USB-DC cord: Contact Miles Research for additional information or technical support Jon Miles Miles Research...
