ASSEMBLY

INSTRUCTION

Remove the inner linings as

indicated in the communicator's

user manual.

Place the right speaker (R) in its

seat on the velcro.

Repeat the operations performed

for the right (R) speaker for

positioning the left (L).

Place the microphone base under

the chinstrap.

Table of Contents

Need help?

Do you have a question about the Just Speak Evo and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTION Remove the inner linings as indicated in the communicator’s user manual. Place the right speaker (R) in its seat on the velcro. Repeat the operations performed for the right (R) speaker for positioning the left (L). Place the microphone base under the chinstrap.
Page 2 ASSEMBLY INSTRUCTION Adjust the position of the microphone by deforming the boom and insert it in the relative seat indicated by the symbol of the microphone on the shell left side. WARNING: check that the triangle on the microphone is facing the mouth. Before assembling the cheekpads, pass the remote control with its flat cable in the...
Page 3 ASSEMBLY INSTRUCTION Place the USB socket between the inner linings and the shell. Stick the remote control on the side of the shell verifying the correct adhesion.
