ASSEMBLY

INSTRUCTION

Remove the anti-noise inserts by

pulling them out of the chinstrap.

on the cheekpad's pp plate after

applying the adhesive round

shaped velcro included in the

package.

Repeat the operations performed

for the right (R) speaker for

positioning the left (L).

Without pulling the chinstrap

out of the cheekpads, pass the

microphone cable and the flat

cable of the remote control into

the hole of the cheekpads.

Table of Contents

Need help?

Do you have a question about the Just Speak Evo and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTION Remove the anti-noise inserts by pulling them out of the chinstrap. Place the right speaker (R) on the cheekpad’s pp plate after applying the adhesive round shaped velcro included in the package. Repeat the operations performed for the right (R) speaker for positioning the left (L). Without pulling the chinstrap out of the cheekpads, pass the microphone cable and the flat...
Page 2 ASSEMBLY INSTRUCTION Pass the flat cable of the remote control cable between the neckroll’s pp plate and the shell. The remote control must remain accessible outside the helmet. Place the base of the microphone under the cheekpads, place the microphone’s boom in the seat ensuring that the neckroll pp plate has been previously positioned against the shell.
Page 3 ASSEMBLY INSTRUCTION House the cable that connects the right speaker to the left between the rear cushion and the neckroll. Stick the remote control on the side of the shell verifying the correct adhesion.
