LockNet Sur-Lock 2000EE Installation Instructions Manual page 4

LOCKNET SUR-LOCK™ EE
Figure 2
Item Qty Part No
1
01 2011-02
1
02 2012-01
1
02 2012-02
2
03 8402-01
2
04 8017-03
1
05 8018-01
06 1 3215-01
4
07 8001-01
4
08 8003-01
09 1
3214-01
1
10 1025-01
1
11 8440-01
Document Part # 7904-03 (Rev 022019)
Description
Alarm Sub Assembly
Latch Sub Assembly Left Hand Rev
Latch Sub Assembly Right Hand Rev
Screw, 10-32 X 3/8 Indented Hex
1/4" Flat Washer
Cotter Pin 1/16" Dia. 3/4" L
Outside Door Strap, 10 Ga
Carriage Bolt 1/4-20 X 2 ½
Nylon Insert Nut 1/4-20
Outside Door Plate
Handle - Modified & Packaged Hdw
Essex 3" x 4" Keypad
Item Qty Part No
1
12 3216-01
8
13 8417-01
1
14 3219-01
1
15 3221-01
1
16 8435-01
1
17 3220-01
18 1 8434-01
1
19 8445-01
1
20 1008-01
1
21 14001002
1
22 14001006
Figure 1
JAMB NUT
Figure 3
Description
Lock Assy Cover #4 Painted
10 X 1/2 Torx Security Screw
Lock Assy Cover #1 Painted
Lock Assy Cover #2 Painted
Key Switch - Lock With Nut
Lock Assy Cover #3 Panted
Cam Lock
Electronic Cable Approx 4'
Latch Assembly
Cable Stub Harness 12 Con
Key, Fort Lock Gem Tube 25236
Page 4 of 6
