HANDING of UNIT
FIELD REVERSIBLE
Refer to both sides of this sheet or
Appendix A of the Installation
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1. Remove the Battery Bracket Assembly and the Lock Bolt Housing Assembly (both are held on
with 2 screws).
IS
Instructions
Battery Bracket
Assembly
Lock Bolt
Housing
Assembly
Advertisement
Table of Contents
Related Manuals for LockNet SurLock I/O2000L Series
Summary of Contents for LockNet SurLock I/O2000L Series
- Page 1 HANDING of UNIT FIELD REVERSIBLE Refer to both sides of this sheet or Appendix A of the Installation Instructions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1.
- Page 2 . . . Continued 2. Remove the Cotter Pin and Washers that secure the Lock Bolt Rod to the top post on the Pivot Plate. 3. Remove the Lock Bolt Rod and reinstall it through the opening on the opposite side, securing it to the bottom post on the Pivot Plate using the Washers and Cotter Pin.
