Tools Needed - LockNet Sur-Lock 2000EE Installation Instructions Manual

• 1/4" Drill Bit
• 1-1/8" Hole Saw
• 7/16" Deep Socket
• 1/8" Drill Bit
1. To locate the area where the device is to be installed on the door, measure 45"
up from the bottom of the door. Make a mark. This mark is used to locate the
top of the door drill template, on retro fit doors. Remove all door hardware
located in the area where the lock is to be installed.
2. Drill (6) holes in the door using the door drill template. Following the instructions
on the drill template, drill four (4) 1/4" and two (2) 1-1/8" holes in the door. NOTE:
The door must be in the closed position for correct placement location of the drill
template.
3. From the outside of the door, align the stainless flat bar, (figure 1, item #06) with
the two (2) 1/4" holes drilled in the center of the door; push two (2) 1/4-20 X 2-
1/2 bolts through the door.
IMPORTANT: Make sure the wiring for the keypad is pushed through the 1-1/8"
hole in the door. Secure the device to the door using the nylon insert nuts (figure
1, item #08).
4. Place the stainless plate (figure 1, item #9) over the shaft and push two (2) 1/4-
20 carriage bolts through the plate, door, and device. Secure with two (2) lock
nuts (figure 1, item #08). CAUTION: Do not over tighten bolts as this may cause
the door to bow.
5. Complete the handle and handle hardware installation (figure 1, item #10) by
installing the plastic ring over the shaft (the cutout over key); install the pin into
the hole in the shaft, centering the pin in the shaft. Push the handle onto the
shaft. Align the cutout in the handle with shaft pin. Tighten with 1/4 20 bolt.
Make sure the handle operates freely. Place the sticker on the handle.
6. Check the distance of the locking rod from the door jamb stop. The locking rod
should just clear the door stop. If necessary, adjust the locking rod by loosening
the jamb nut (figure 3) and turning the locking rod as needed to obtain the
proper clearance. Once adjusted, tighten the jamb nut securely.
Document Part # 7904-03 (Rev 022019)

TOOLS NEEDED

• Exterior Silicon Caulk
• 3/8" and 7/16" Open End Wrench
• Torx T25 Security Wrench (Supplied)
Mount the device to the inside of the door.
Page 2 of 6
