www.ergotron.com
User's Guide - English
Guía del usuario - Español
Manuel de l'utilisateur - Français
Gebruikersgids - Nederlands
Benutzerhandbuch - Deutsch
Guida per l'utente - Italiano
Användarhandbok - svenska
ユーザーガイ ド : 日本語
用户指南 : 汉语
Important! You will need to adjust this product after installation is complete. Make sure all your equipment is properly installed on the product
before attempting adjustments. This product should move smoothly and easily through the full range of motion and stay where you set it. If
movements are too easy or diffi cult or if product does not stay in desired positions, follow the adjustment instructions to create smooth and easy
movements. Depending on your product and the adjustment, it may take many turns to notice a diff erence. Any time equipment is added or
removed from this product, resulting in a change in the weight of the mounted load, you should repeat these adjustment steps to ensure safe and
optimum operation.
888-45-221-W-04 rev.K • 10/14
Interactive TV Arm: 45-296-026: OM1100549
MAXIMUM WEIGHT CAPACITY
CAUTION!
40 LBS
18.1 KG
User's Guide
Guía del usuario
Manuel de l'utilisateur
Benutzerhandbuch
Gebruikersgids
Guida per l'utente
Användarguide
ユーザーガイド
用户指南
사용자 안내서
CAUTION!
MAXIMUM SCREEN SIZE
55"
1 of 17
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ergotron 45-296-026
Summary of Contents for Ergotron 45-296-026
- Page 1 Interactive TV Arm: 45-296-026: OM1100549 User's Guide Guía del usuario Manuel de l’utilisateur Benutzerhandbuch Gebruikersgids Guida per l’utente Användarguide ユーザーガイド 用户指南 사용자 안내서 www.ergotron.com User's Guide - English Guía del usuario - Español Manuel de l’utilisateur - Français Gebruikersgids - Nederlands Benutzerhandbuch - Deutsch Guida per l’utente - Italiano...
- Page 2 CONTENTS Part Quantity Description Wall Plate Arm/Wall Plate Hardware Wall Plate Covers Rear Arm Cover CFT Arm 200x200 VESA Monitor Plate Spider Adapters Screws/Hardware For Flat Panel 697-613-00 Wall Kit ST8x2 697-641-00 Part Quantity Description Part Quantity Description Philips screws M4 x 15mm Lag Bolt Philips screws M4 x 30mm Round Washers...
-
Page 3: Tools Needed
CAUTION! CAUTION! TOOLS NEEDED MAXIMUM WEIGHT CAPACITY MAXIMUM SCREEN SIZE Tools Needed Herramientas necesarias 55” Outils requis Benötigte Werkzeuge Benodigde gereedschappen 40 LBS Strumenti necessari Potrzebne narzędzia 18.1 KG Potřebné nástroje Szükséges eszközök Απαιτούμενα εργαλεία Ferramentas necessárias Nødvendigt værktøj Tarvittavat työkalut Verktyg som krävs Instrumente necesare Необходими... -
Page 4: Mounting Considerations
INSTRUCTIONS 1. MOUNTING CONSIDERATIONS: • Wall Mount Bracket MUST be attached to a stud or solid concrete. DO NOT attach this product to hollow wall or any other confi guration. • Make sure Arm will have desired unobstructed range of motion: up-down, side-to-side, in-out (see section RANGE OF MOTION). •... - Page 5 Wood Stud Mount 7/32 x 2.75" 5.5mm x 70mm 888-45-221-W-04 rev.K • 10/14 5 of 17...
- Page 6 Solid Wall Mount 3/8 x 2.75" 9.5 - 10mm x 70mm 888-45-221-W-04 rev.K • 10/14 6 of 17...
- Page 7 65mm Washer 16mm Bearing Spring Disc 25mm Washer NOTE: Part# P-H must be concave face down for proper assembly. 888-45-221-W-04 rev.K • 10/14 7 of 17...
- Page 8 200mm (7-7/8”) 100 x 200 200 x 200 200mm (7-7/8”) 200 x 300 200 x 400 600mm (23-5/8”) 400mm (15-3/4”) 300 x 300 300mm (11-13/16”) 300 x 400 400 x 400 600 x 400 400mm (15-3/4”) 300mm (11-13/16”) 300 x 200 400 x 200 888-45-221-W-04 rev.K •...
- Page 9 200mm (7-7/8”) 100 x 200 200 x 200 200mm (7-7/8”) WARNING! PLEASE SELECT THE PROPER SCREW LENGTH FOR YOUR FLAT PANEL BY HAND TIGHTENING TO CHECK YOUR FLAT PANELS THREAD DEPTH. 888-45-221-W-04 rev.K • 10/14 9 of 17...
- Page 10 300 x 200 200 x 300 300 x 300 200 x 400 300 x 400 400 x 200 400 x 400 600 x 400 200mm 600mm 400mm 400mm 300mm 300mm 400mm 600mm 888-45-221-W-04 rev.K • 10/14 10 of 17...
- Page 11 B / C / D WARNING! PLEASE SELECT THE PROPER SCREW LENGTH FOR YOUR FLAT PANEL BY HAND TIGHTENING TO CHECK YOUR FLAT PANELS THREAD DEPTH. 888-45-221-W-04 rev.K • 10/14 11 of 17...
- Page 12 NOTE: Leave enough slack in cable to allow full range of motion. Caution: To avoid the potential to pinch cables it is important to follow the cable routing instructions in this manual. Failure to follow these instructions may result in equipment damage or personal injury.
- Page 13 Adjustment Step Important! You will need to adjust this product after installation is complete. Make sure all your equipment is properly installed on the product before attempting adjustments. This product should move smoothly and easily through the full range of motion and stay where you set it. If movements are too easy or diffi cult or if product does not stay in desired positions, follow the adjustment instructions to create smooth and easy movements.
- Page 14 Lift – Up and down Elevación (arriba y abajo) Ajustement en hauteur : bas et haut Höhenverstellung – rauf und runter Verstel in hoogte – Omhoog en omlaag Sollevamento – Su e Giù Lyft – upp och ned リフト(上下) 升降（上下） 높이...
- Page 15 Increase Friction If this product moves too easily from side-to-side, then you'll need to increase friction: Decrease Friction If this product is too diffi cult to move from side-to-side, then you'll need to decrease friction: 888-45-221-W-04 rev.K • 10/14 15 of 17...
- Page 16 Increase Friction If this product moves too easily from side-to-side, then you'll need to increase friction: Decrease Friction If this product is too diffi cult to move from side-to-side, then you'll need to decrease friction: CAUTION! The bottom nut will turn during adjustment of the top nut; DO NOT apply any tool to the bottom nut.
- Page 17 Tilt – Forward and Backward Inclinación (adelante y atrás) Inclinaison : Avant et arrière Neigung – vor und zurück Kantel – Naar voren en naar achteren Inclinazione – Avanti ed Indietro Vinkla – framåt och bakåt チルト (前後) 倾斜（前后） 기울기 – 앞/뒤로 888-45-221-W-04 rev.K •...
