TECP-90-801  Issue 4  October 2017
Quareo High Density Equipment Panel (HDEP)
Content
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
RELATED PUBLICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1
PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1
1.2
1.3
1.4
2
UNPACKING AND INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3
INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1
3.2
3.3
3.4
3.5
3.6
3.7
3.8
3.9
4
INSTALLING MODULES AND IFC CABLES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
5
TECHNICAL ASSISTANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
300100102902 Rev D
This product is covered by one or more U.S.patents or their foreign equivalents.
For patents, see
http://www.commscope.com/ProductPatent/ProductPatent.aspx
Physical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Panel Electronics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Status LEDs on Front Panel and Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Tools and Hardware Needed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Rack Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing the Vertical Cable Guides (VCGs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Grounding the Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Installing the Management Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Connecting the Ethernet Cable and AUX Power Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Connecting the Control Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Connecting the Panel to the Quareo Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
User Manual
25111-A
Page
Page 1
© 2017 CommScope.
All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quareo HDEP Series and is the answer not in the manual?

Questions and answers

Summary of Contents for CommScope Quareo HDEP Series

  • Page 1: Table Of Contents

    TECHNICAL ASSISTANCE..............16 300100102902 Rev D Page 1 © 2017 CommScope. This product is covered by one or more U.S.patents or their foreign equivalents. For patents, see http://www.commscope.com/ProductPatent/ProductPatent.aspx...
  • Page 2: Introduction

    Instructions unique to the various module types are provided through QR code access to the CommScope Field Support Link. This online site contains videos, animations, and other information for the module being installed. The QR code is a label on the top of the panel;...
  • Page 3: Related Publications

    18 of the National Electrical Code, ANSI/NFPA 70 RELATED PUBLICATIONS Listed below are related manuals and their publication numbers. Copies of these publications can be ordered by contacting the CommScope Technical Assistance (refer to Topic 5 on Page 16). Title/Description...
  • Page 4: Product Description

    • QR code—is a label with a pattern recognizable by a visual recognition app on a smart phone. The QR code causes the smart phone to link to the CommScope Field Support Link, which contains user instructions specific to the 1RU panel.
  • Page 5: Panel Electronics

    2). These LEDs are identical in function. There is one LED for each access tray. The LEDs have two states: unlit or lit (green). ACCESS TRAY 25315-A FRONT MIDDLE OF PANEL LEDs Figure 2. Status LEDs Page 5 © 2017 CommScope. All Rights Reserved.
  • Page 6: Specifications

    13.35 in (33,9 cm) D x 19.01 in (48.29 cm) W x 1.7 in (4.32 cm) H Weight 4.1 lb. (1.86 kg.) Components Supported Adapter Packs* LC-LC 24 fibers (12 duplex ports) MPO-MPO 192 fibers (eight 24-fiber ports) Page 6 © 2017 CommScope. All Rights Reserved.
  • Page 7: Unpacking And Inspection

    3. If damage is found or parts are missing, file a claim with the commercial carrier and notify CommScope Customer Service. Save the damaged cartons for inspection by the carrier. 4. Refer to Topic 5 on Page 16 if you need to contact CommScope.
  • Page 8: Overview

    Each panel is secured with either 12-24 screws, M6 hardware, or TrueNet quick fit hardware depending on type of mounting used. Use the following procedure to mount the panel (refer to Figure Page 8 © 2017 CommScope. All Rights Reserved.
  • Page 9 For a19-inch rack or cabinet, remove the ETSI brackets and leave the inner mounting brackets in place. c. For an 23-inch rack or cabinet, remove the ETSI brackets and in their place install the 23-inch extender brackets (provided in ship along kit). Page 9 © 2017 CommScope. All Rights Reserved.
  • Page 10: Installing The Vertical Cable Guides (Vcgs)

    3. Press the VCG into position in the panel as shown in Figure Note: Make sure the leading edge of the VCG is inserted under the guide rails as shown in Figure Page 10 © 2017 CommScope. All Rights Reserved.
  • Page 11 TECP-90-801 • Issue 4 • October 2017 FRONT VIEW OF FRAME 26575-A VERTICAL CABLE GUIDE (VCG) Figure 4. Orienting VCG With Panel (Shown Here Without Extension Bracket) 26576-A Figure 5. Inserting VCG in Panel Page 11 © 2017 CommScope. All Rights Reserved.
  • Page 12 TECP-90-801 • Issue 4 • October 2017 26577-A Figure 6. Pressing VCG Into Position GUIDE RAILS GUIDE FRAME RAILS SHOWN CLARITY 25409-A Figure 7. Make Sure to Insert VCGs Behind Guide Rails Page 12 © 2017 CommScope. All Rights Reserved.
  • Page 13: Grounding The Panel

    3. Connect the other end of the ground wire to the earth ground conductor. Ensure this connection is made using methods and hardware that meets all applicable local and national electrical codes. Figure 8. HDEP Ground Location Page 13 © 2017 CommScope. All Rights Reserved.
  • Page 14: Installing The Management Unit

    The Ethernet port supports a maximum cable length of 328 feet (100 meters) to a switch. Pins 1, 2, 3, and 6 (See Figure 9) are used in 10BASE-T (10Mb/s) and 100BASE-TX (100Mb/s) networking. Set PoE switch to auto-negotiate, the controller Ethernet port supports 10/100Mb/s. Page 14 © 2017 CommScope. All Rights Reserved.
  • Page 15: Connecting The Panel To The Quareo Network

    Instructions for performing the software procedure described above can be found in TECP-90- 805, which is available on the CommScope website. 4 INSTALLING MODULES AND IFC CABLES Note: Remove the dust cap, inspect, and clean MPO connector per ADCP-96-150 instructions before terminating.
  • Page 16: Technical Assistance

    Instructions unique to the various module types are provided through QR code access to the CommScope Field Support Link. This online site contains video, animations, and other information for the specific module being installed.

Table of Contents
