PRE-INSTALLATION CARD ART. 220M
C
- Hot water connection for
F
- Cold water connection for tap fittings
O
- Connection for drainage pipe recessed in floor
CA - Electrical connection for Hydromassage IPX5
(box with cable press PG 13.5)
The electrical installation must comply with the safety regulations for bathroom installation, as
described in the enclosed user's manual.
ART. 220 M
Net
Water
Floor
Delivery
Delivery
Weight
Content
(1)
Load
Weight
Volume
Kg.
Kg.
Kg/m
2
Kg.
m
175 300
270
291
4,6
(1) - At overflow level
The information and characteristics shown do not bind Teuco Guzzini Spa who reserves the right to make any modifications it retains necessary without any prior warning or notice of replacement.
18
1
2 "
tap fittings
N.B. Installation must take place once floors and
/
walls are completed.
1
2 "
/
Ø40mm
HYDRAULIC CHARACTERISTICS
Hydromassage
Water
Vers.
Air
Vert.
3
Capacity
Capacity
Jets
No. Jets
400
280
TOP 8
6
l/min.
l/min.
(2) - Before connecting the appliance, make sure that the voltage indicated on the rating plate is the same as that of the electric mains.
(mm 1330 x 1330)
Multifunctions
Supply
Foot
Capacity
Min.Max.
Jets
l/
Pressure
min
2 ÷ 5
2
1/2"
9 ÷16
bar
Measurements in mm.
Siphon
160
ELECTRICAL
CHARACTERISTICS
Whirlpool
Installed Power
Drain
Conn.
Art.
Ø40
2WTX28
mm
(2)
Kw
1,35
