User's Manual
Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Part Names and Functions . . . . . . . . . . . . . . . . . . . 3
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cleaning the Product . . . . . . . . . . . . . . . . . . . . . . . 14
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Product Specifications . . . . . . . . . . . . . . . . . . . . . . 17
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
M00104402 EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the TM-T88VI-iHUB and is the answer not in the manual?

Questions and answers

Related Manuals for Epson TM-T88VI-iHUB

Summary of Contents for Epson TM-T88VI-iHUB

  • Page 1: Table Of Contents

    User’s Manual Before Use ........2 Part Names and Functions ....3 Setup .

  • Page 2: Before Use

    English Before Use Please read this manual carefully before using this product. Keep this manual at hand for immediate reference whenever necessary. For details about the functions and operation procedure of this product and software, refer to Technical Reference Guide. Key to Symbols The symbols shown below are used in this manual in order to ensure safety and proper use of this product and to prevent danger to customers and other persons, and property damage.

  • Page 3: Part Names And Functions

    English Part Names and Functions Control panel NFC Tag A mark is printed here to indicate the position of the NFC tag. To establish communication with an NFC device, bring the device close to this mark. For details on functions that use the NFC tag, see the Technical Reference Guide.
  • Page 4 English Control Panel (Power) LED This LED is on when the printer is on. (Error) LED This indicates an error. (Paper) LED On indicates a paper near end or out. Flashing indicates standby. Feed button Press this button once to feed the roll paper for one line. Hold down this button to continue feeding the roll paper.
  • Page 5 English Interface All the ports and connectors are located on the back of the printer. Drawer kick connector Connects the modular cable for the cash drawer. Ethernet port Connects the 10 BASE-T/100 BASE-TX LAN cable. Serial port Use only for connecting external devices. USB Type A port Use only for connecting external devices.

  • Page 6: Setup

    English Setup Installing the Printer Install the printer horizontally on a flat surface. Connecting the AC Adapter WARNING: Be sure to use the specified AC adapter [AC adapter,V (Model: M344A)]. Connection to an improper power source may lead to equipment damage, fire, or electric shock. 1.
  • Page 7 English Connecting External Devices If you connect external devices, connect each cable to the port/connector on the back of the printer. (U “Interface” on page 5 CAUTION: ❏ When connecting external devices to the USB ports, follow the precautions below. •...
  • Page 8 English 3. Push the connector cover down to click onto the printer case. Note: ❏ You can use the enclosed screw to fix the connector cover. ❏ To remove the connector cover, turn the printer over, remove the screw, and push the connector cover down while pushing both sides of the connector cover inward to detach the hooks from the printer case.
  • Page 9 English Arranging the Cables Pass the cables through cable exits in the connector cover. Some cables can be routed out from the front by passing them through the notch in the printer bottom. Note: ❏ When using cables without lock, use of the bundled cable lock band is recommended. Bundled cable lock band ❏...
  • Page 10 English After the cable arrangement, turn over the printer, and make sure the cables are not pinched. Attaching the Power Switch Cover By attaching the power switch cover, you can prevent accidental operations of the power switch. You can turn on and off the power switch by inserting a sharp-pointed object in the holes on the power switch cover.
  • Page 11 English Changing the Paper Width You can change the paper width from 80 mm to 58 mm by installing the roll paper guide. Follow the steps below to change the paper width. 1. Turn off the printer. 2. Open the roll paper cover. 3.

  • Page 12: Installing/Replacing The Roll Paper

    English Installing/Replacing the Roll Paper Follow the steps below to install and replace the roll paper. 1. Open the roll paper cover. 2. Remove the used roll paper core if any. 3. Install the roll paper in the correct direction.
  • Page 13 English 4. Pull out some paper, and close the roll paper cover. 5. Tear off the paper.

  • Page 14: Cleaning The Product

    Cleaning the Thermal Head and the Platen Roller Epson recommends cleaning the thermal head to maintain receipt print quality. We recommend cleaning periodically (about once every 3 months). Depending on the roll paper used, paper dust may stick to the platen roller and the paper may not be fed correctly.

  • Page 15: Troubleshooting

    English Troubleshooting No lights on the control panel Check whether the power supply cable is correctly connected to the printer and the socket. (Error) LED on with no printing ❏ Check whether the roll paper cover is closed. If it is open, close the cover. ❏...
  • Page 16 English 2. Slide the cutter cover toward the front to open it. 3. Turn the knob until you see a triangle in the opening. This returns the cutter blade to the normal position. There is a label near the cutter to assist you. a.

  • Page 17: Product Specifications

    English Product Specifications Printing method Thermal line printing Roll paper Paper width 80 mm paper width setting: 79.5 mm ± 0.5 mm {3.13" ± 0.02"} 58 mm paper width setting: 57.5 mm ± 0.5 mm {2.26" ± 0.02"} External diameter Maximum 83 mm {3.27"} Core internal 12 mm {0.47"}...

  • Page 18: Appendix

    Trademark EPSON is a registered trademark of Seiko Epson Corporation. Exceed Your Vision is a registered trademark or trademark of Seiko Epson Corporation. All other trademarks are the property of their respective owners and used for identification...
  • Page 19 Neither is any liability assumed for damages resulting from the use of the information contained herein. Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson...
