MODELS:
PAVER-CP-MT
PAVER-CP-MT-MSI
Paver Control Panel Kits
Stainless Steel Control Panel for use with Fire Pits built with Patio Paver Blocks
Installation and Operating Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
CALIFORNIA PROPOSITION 65
WARNING
This product is designed to operate with one of the following fuel sources: Liquid Propane or Natural Gas. The fuel used to operate this product, and
the products of combustion of such fuel, can expose you to chemicals including Benzene which is known to the State of California to cause cancer, birth
defects and other reproductive harm and Carbon Monoxide which is known to the State of California to cause birth defects or other reproductive harm.
(For more information go to: www.p65Warnings.ca.gov.)
Warning: For Outdoor Use Only
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
REV. 10-18-19 Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PAVER-CP-MT and is the answer not in the manual?

Questions and answers

Related Manuals for Firegear PAVER-CP-MT

Summary of Contents for Firegear PAVER-CP-MT

  • Page 1 MODELS: PAVER-CP-MT PAVER-CP-MT-MSI Paver Control Panel Kits Stainless Steel Control Panel for use with Fire Pits built with Patio Paver Blocks Installation and Operating Instructions IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE...
  • Page 2 Piezo ignition (if applicable) then is easily removed for servicing. PRECAUTION: If you are installing the MSI (Manual Spark Ignition) ensure the PAVER-CP-MT-MSI control panel is within 40-inches of the 2-probe Piezo ignitor. This will allow enough “play” in the wires to make your connections. See Fig.

  • Page 3: General Instructions

    The lintel simply lays on top of the paver as shown in Fig. 5 Front view of control panel installed, ready for valve Fig. 4. bracket. PAVER-CP-MT INSTRUCTIONS With the paver kit face plate bracket (control panel) Manual Key Valve installed you are now ready to install the manual gas valve.
  • Page 4 See page 5 for lighting instructions. STEP 5: After burn test is complete, finish the patio paver blocks installation. Fig. 8 Close up view securing MT valve bracket to control panel. PAVER-CP-MT/ PAVER-CP-MSI REV. 10-18-19 Page 4...

  • Page 5: Paver-Cp-Mt

    1. Insert key into shut-off valve and secure into square end. 2. Turn key clockwise until it stops. 3. After cooling off install cover. Fig. 10 Inserting Key into Valve Fig. 11 Lighting fire pit with lighter PAVER-CP-MT-MSI INSTRUCTIONS ” Tools Needed: Power Screwdriver with a hex head ”...
  • Page 6 Fig. 13. Installing MSI assembly into bottom of pan. Top of Pan Tabs Center Burning Spur Leg Mounting Plate Plastic Nut Fig. 14. Installing screws from bottom of pan. Red Button Cap Fig. 16 Installing battery into Piezo module. PAVER-CP-MT/ PAVER-CP-MSI REV. 10-18-19 Page 6...
  • Page 7 Lava Rock PIEZO48WH Orange Wire Manual Key Valve Ignition Hood Ignition Hood PIEZO23WH Screen Piezo Module Lava Rock Gas Supply Fig. 19 Wiring diagram PAVER-CP-MT-MSI. Fig. 20 Installing screen mesh cover on ignitor hood. PAVER-CP-MT/ PAVER-CP-MSI REV. 10-18-19 Page 7...

  • Page 8: Paver-Cp-Msi

    LIMITED WARRANTY Firegear Outdoors warrants the Paver Kit for 12 months from date of purchase or installation to original purchaser to be free from defects in materials and workmanship. Damage to the Paver Kit caused by accident, misuse, abuse, or installation error, whether performed by a contractor, service company, or owner, is not covered by this warranty.

  • Page 9: Replacement Parts

    PAVER-CP-MT / PAVER-CP-MT-MSI REPLACEMENT PARTS Drawings not to Scale Item # Qty. Description Part Number MT MT-MSI Paver Kit Bracket PAVERKITBRACKET-SS Paver Kit Bracket Extension PAVERKITBRACKETEXT-SS 10-24 x ½” SS Thread Cutting Screw ST3-113-1028 ½” Stainless Thread Cutting Screw SCREW1024HXSS75 MSI Ignitor Assembly ( 24”...
  • Page 10 FOR TECHNICAL SERVICE, CALL: (855) 498-8324 Firegear Outdoors 9230 Conservation Way Fort Wayne, IN 46809 Sales: (888) 672-8929 Sales Support: (888) 699-6167 Tech Support E-mail: www.support@firegearoutdoors.com WEB SITE: www.firegearoutdoors.com PAVER-CP-MT/ PAVER-CP-MSI REV. 10-18-19 Page 10...
