MODEL:
PAVER-CP-TMSI
PAVER CONTROL PANEL - TMSI
Stainless Steel Control Panel for use with Fire Pits built with Patio Paver Blocks
Installation and Operating Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS PRODUCT
CALIFORNIA PROPOSITION 65
WARNING
This product can expose you to Chromium, which is
known to the state of California to cause cancer
and birth defects or other reproductive harm.
(For more information, go to www.p65warnings.ca.gov)
Warning: For Outdoor Use Only
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
Advertisement
Table of Contents
Related Manuals for Firegear PAVER-CP-TMSI
Summary of Contents for Firegear PAVER-CP-TMSI
- Page 1 MODEL: PAVER-CP-TMSI PAVER CONTROL PANEL - TMSI Stainless Steel Control Panel for use with Fire Pits built with Patio Paver Blocks Installation and Operating Instructions IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO NOT ATTEMPT TO INSTALL OR OPERATE THIS PRODUCT...
- Page 2 Piezo ignition (if applicable) then is easily removed for servicing. PRECAUTION: Ensure the PAVER-CP-TMSI control panel is within 40-inches of the 2-probe Piezo ignitor. This will allow enough “play” in the wires to make your connections. See Fig. 9.
- Page 3 STEP 1: Prepare the fi re pit gas valve by installing a ⅜” close nipple and ½” OD Flare x ⅜” brass fi tting that comes with the PAVER-CP-TMSI kit into the gas inlet. Use gas rated Tefl on (U1-8C-S) tape or compound on the male threads.
- Page 4 Note: The Piezo wires are not polarity senstive therefore they can plug into either connection of hte Piezo module. Check for gas leaks before final assembly. Fig. 7. Installing fittings. Inlet Gas Supply Piezo From Connections Fire Pit PAVER-CP-TMSI REV. 8-24-18 Page 4...
- Page 5 STEP 10: After burn test is complete, finish the patio paver block installation per the install manual. Fig. 9 Installing TMSI valve into Paver Kit Bracket. Fig. 10 Close up view securing TMSI valve bracket to control panel. PAVER-CP-TMSI REV. 8-24-18 Page 5...
- Page 6 ON. Ignition Hood Installation is now complete. Screen Lava Rock Fig. 12 Installing mesh cover on the ignitor shield. CAUTION: ENSURE YOU HAVE LEAK TESTED THE FIRE PIT BEFORE LIGHTING AND OPERATING. PAVER-CP-TMSI REV. 8-24-18 Page 6...
- Page 7 SLIGHT PUSH TO will turn OFF. TURN OFF 2. After cooling off install cover. FULL PUSH TO LIGHT Fig. 13 TMSI control knob. PAVER-CP-TMSI REPLACEMENT PARTS Drawings not to Scale Item # Qty. Description Part Number Paver Kit Bracket PAVERKITBRACKET-SS...
- Page 8 LIMITED WARRANTY Firegear Outdoors warrants the Paver Kit for 12 months from date of purchase or installation to original purchaser to be free from defects in materials and workmanship. Damage to the Paver Kit caused by accident, misuse, abuse, or installation error, whether performed by a contractor, service company, or owner, is not covered by this warranty.
