HiB Stratus 50 Fitting Instructions

Led illuminated steam free cabinets

Advertisement

Quick Links

LED Illuminated Steam Free Cabinets
Stratus 50
Stratus 60
Art No.
46800
Art No.
46900
Thank you for purchasing this HiB product.
Please read through these instructions carefully and refer back to them during installation to ensure that
your product is fitted safely and that it retains its high quality finish.
Please retain this leaflet for future reference.
Before drilling, ensure there are no hidden cables or pipes in the wall.
Please Note these products must be installed with a minimum distance
of 150mm between the infra-red sensor switch and any surface or object
to ensure correct operation of the sensor.
Min. 150mm
FI
#02 009 R151005
Ver No.
1.0 Jan 2016
