- Page 1 NLS-CM50 Area Imaging Engine Integration Manual...
- Page 2 The information in this publication does not representa commitment on the part of Newland. Newland shall not be liable for technical or editorial errors or omissions containedherein; nor for incidental or consequential damages resulting from the furnishing,performance, or use of this material.
-
Page 3: Table Of Contents
Table of Contents Preface ..........................................1 About This Manual ..................................... 1 Chapter Introduction ....................................1 Chapter 1 Introduction and Installation ................................2 About CM50 ....................................... 2 ESD Precautions ......................................2 Unpacking the Engine ....................................2 Dust and Dirt ....................................... 2 Mounting Orientation .................................... - Page 4 Serial Command Interface ..................................15 Read-out a Register ................................... 15 Read-out Adjacent Registers ................................15 Write-in a Register .................................... 15 Write-in Adjacent Registers ................................16 Suspend ......................................16 Operating Mode ......................................16 Standby Mode ....................................16 Ready Mode ...................................... 16 CIS Standby Mode ....................................
-
Page 5: Preface
Preface About This Manual This Integration Manual provides specifications and installation instructions for the engine. Chapter Introduction Introduction and Installation provides the installation instructions for the engine. Mechanical Specificationsprovides the dimensions, interface connector and some design proposals. Electrical Specificationsdescribes DC Characteristics and AC Characteristics. -
Page 6: Chapter 1Introduction And Installation
NLS-CM50 Area Imaging Engine, with small size and full automation design, is ideal as drop-in modules for OEM applications. Combined with Newland`s decoding software, NLS-CM50 can easily read all kinds of 2D and 1D bar codes as well as OCR fonts. -
Page 7: Interface Connector
Interface Connector Molex Connector 501912-2190 drawings taken from Molex Catalog page MX01. 0.3mm (0.012 in.) SMT, ZIF, Bottom Contact. Be carefulwhen handling the connector and flex strip so as to avoid any damage to the connector. The connection between flex strip and the connector should be solid and effective to ensure the engine`s normal work. -
Page 8: Connector Pinout
Connector Pinout Signal Name Description Power and signal ground. Reserved Reserved. (suggested to be connected to GPIO of microprocessor) Power and signal ground. HSYNC High-when pixel data output (LINE_VALID) VSYNC High-when pixel data output (FRAME_VALID) Aimer LED controller, effective in high level. When Aimer is set under control of this pin, Aimer will be open in high level and off in low level. -
Page 9: Chapter 2 Mechanical Specifications
Chapter 2 Mechanical Specifications Outside View and Dimension CM50 Top-side View Unit：mm CM50 Front-side View Unit：mm CM50 Left-side View Unit：mm... -
Page 10: Cm50 Bottom-Side View
CM50 Bottom-side View Unit：mm Connector The connector of CM50 isMolex 501912-2190. -
