- Page 1 Genesis Rollator item #: 10444SL www.drivedevilbiss.co.uk...
- Page 2 Parts List Item # 10444SL WEIGHT CAPACITY: 300lbs / 136kg / 21 stone 10. Plastic Connecting Base 1. Handgrip 11. Front Wheel 2. Hand Brake 12. Front Wheel Fork 3. Handle Tube 13. Height Adjust Button 4. Seat Tube 14. Black Pull Tab 5.
- Page 3 Introduction The Walking aid is suitable for a single user with limited mobility. The Genesis Rollator is ideal for indoor and outdoor use. Genesis Rollator Includes: 1. Bag 3. Can Holder 2. Back Rest 4. Operating Instructions Unfolding The Genesis Position the Genesis on its wheels.
- Page 4 Installing The Backrest Slide the plastic ends of the backrest circled in Figure 3 onto the rails on the handles. Tighten the screw to lock the backrest in place. Screw Figure 3 Height Adjustment Push the black release buttons and simultaneously move the handgrip upwards or downwards.
- Page 5 Removing / Attaching The Carry Bag Before attaching the bag, insert the two support rods into the rollator seat frame. Screw to tighten until rods are secure. The bag can be attached or removed by using the Velcro straps on both sides of the bag (Figure 5). Support Velcro Strap...
- Page 6 Sitting Position the Genesis on an even and solid surface. Lock the brakes (parking position). The Genesis must stand and must not slip. Sit straight up and do not lean backwards. DO NOT MOVE ROLLATOR WHILE SEATED. Folding / Transport / Storage The Genesis rollator may be folded with our without the bag attached.
- Page 7 Using The Universal Cane Holder The Genesis rollator comes with a cane holder attachment that can be used with tri-tip or single tip canes (Figure 11). To install the cane holder base, rotate so that the “T” shapes line up. Insert the base and rotate back.
- Page 8 If you have a question about your Drive device or this warranty, please contact an authorized Drive dealer. Drive Devilbiss Healthcare Ltd, 1 Heathfield Lane, Birkenshaw West Yorkshire, GB BD11 2HW www.drivedevilbiss.co.uk...
