Display – Zeichen und Symbole
abk. Beschreibung
R:
Entfernung (Schrägdistanz)
EHR: äquivalente horizontale
Entfernung
ELE: Neigungswinkel
AZI: Azimut
56
R
AZI
EHR
ELE
