BEZEICHNUNG DER TEILE
1
1
Batteriefachabdeckung
2
Schutzüberzug aus Elastomer
3
Auslösetaste
4
Augenmuschel (umstülpbar)
5
Öse für Umhängeband
42
2
3
4
10
9
5
6
8
6
Okular
7
Stativanschluss 1/4" – 20 UNC
8
Typenschild
9
Objektiv – Sender
10 Objektiv – Tagsichtoptik und Empfänger
5
7
