Summary of Contents for aireRyder F0048
- Page 1 Model No.: F0048 PAGE: 1 / 9 181128...
-
Page 2: Package Contents
Package Contents: Unpack your fan and check the contents. You should have the following items. 1.) Hanger Bracket 2.) Canopy 3.) Decorative Cap 4.) Downrod Stand Cover 5.) Downrod Set (Included Hanger Ball, 6” Downrod, Hanger Pin & Lock Pin) 6.) Fan Motor Assembly 7.) Fan Blades (3PCS) 8.) Blade Holder (3PCS) - Page 3 Exploded View Detail Hanger Bracket Hanger Ball Downrod Canopy Decorative Cap Downrod Stand Cover Hanger Pin Lock Pin Collar Housing Blade Holder Blade Switch Box Switch Box Screw Fan Light Dual Mount Drawing Downrod Mount Slope Ceiling Mount (Up to 23 degrees) PAGE: 3 / 9 181128...
-
Page 4: Safety Instructions
Safety Instructions READ ALL SAFETY INFORMATION AND INSTALLATION INSTRUCTIONS BEFORE YOU BEGIN TO INSTALL THE FAN AND SAVE INSTRUCTIONS. All set screws of the fan must be checked and retightened where necessary before installation. To reduce the risk of personal injury, do not bend the blade brackets when installing the brackets, balancing the blades or cleaning the fan. -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS IMPORTANT: BEFORE YOU BEGIN INSTALLING THE FAN, CAREFULLY READ ALL INFORMATION ON THE SEPARATE SHEET "SAFETY INSTRUCTIONS" AS WELL AS THE FOLLOWING "INSTALLATION INSTRUCTIONS". IF IN DOUBT, CONSULT A QUALIFIED ELECTRICIAN. SAVE ALL INSTRUCTIONS. NOTE: The fan weight is 17.28 lbs (7.84 kgs). Be sure the outlet box you are using is securely attached to the building structure and can support the full weight of the fan. - Page 6 Receiver Antenna There is a code switch in the transmitter and receiver. This "DIP Switch" is a 4 key units (Fig.8). All keys were set at "ON" position in the beginning. Set the keys to a different code. Make sure the same numbered keys DIP Switch are switched "ON"...
- Page 7 Fig.13a Motor Align holes and fasten blade holder to the Blade Holder motor with screws.Then align holes and Screw fasten blade to the blade holder with blade Blade Holder Edge Angle screws.Repeat for remaining blades and blade Motor Blade Screw holders (Fig.12a).
-
Page 8: Trouble Shooting Guide
Trouble Shooting Guide If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation or wiring. If you experience any faults, please check this Trouble Shooting Guide. If a problem cannot be remedied or you are experiencing difficulty in installation, please call our Customer Service Department (1-800-887-6326). - Page 9 DYNAMIC BLADE BALANCING KIT YARDSTICK BALANCING WEIGHT CENTERLINE MEASURING POINT COUNTER- CLOCKWISE PLASTIC CLIP PREFACE Your ceiling fan may sometimes have wobbling problems when operating due to irregularity in the blades or the blade brackets. Improper assembly in the mounting system may cause some additional problems.
