Usb Charging - Letscom ID132Color HR User Manual

Please charge your new device for at least
10 minutes to have it activated before initial
use.
Insert the charging plug of the host into the USB port for
charging. Make sure the pins on the charging plug contact
those in the USB port.
1
3
The red indicator is on when the device is properly charged.
If not, check the direction of the device's charging plug and
move to the correct direction, as shown below.
In case that device is under low battery, connect the device host
to an adapter for charging. Device will automatically boot up once
fully charged. Remove the device host from the power supply
once fully charged.
USB charger requirement: DC USB port (5V-500mA)
Charging time: 1-2hr(s)

USB Charging

2
2
