Summary of Contents for Lec L5017W
- Page 1 L5017W/S/B...
-
Page 2: Table Of Contents
Contents Safety Warnings ..........................3 Unpacking ............................. 5 Installation ............................ 6 Location ..................................6 Levelling the Unit ..............................6 Free Space Requirements ............................6 Reversing the Door Swing .............................7 Cleaning Before Use ............................. 10 Before Using Your Unit ............................10 Product Overview ........................11 Operation ............................ -
Page 3: Safety Warnings
Safety Warnings For your continued safety and to reduce the risk of injury or electric shock, please follow all the safety precautions listed below. • Read all instructions carefully before using the unit and keep them for future reference. • Retain the manual. If you pass the unit onto a third party, make sure to include this manual. - Page 4 • Do not store bottles or glass containers in the freezer compartment. bottle and damage your freezer compartment. (If applicable) WARNING • Keep ventilation openings in the unit enclosure or in the built-in structure clear of obstructions. • Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
-
Page 5: Unpacking
Thank you for purchasing your new LEC Undercounter Fridge. We recommend that you spend some time reading this instruction manual in order that you fully understand all the operational features it offers. Read all the safety instructions carefully before use and keep this instruction manual for future reference. -
Page 6: Installation
Installation INSTALLATION Location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated with an average room temperature of between 16°C and 38°C. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption. -
Page 7: Reversing The Door Swing
INSTALLATION Reversing the Door Swing Tools required: Phillips style screwdriver / Flat bladed screwdriver / Hexagonal spanner • Ensure the unit is unplugged and empty. • To take the door o it is necessary to tilt the unit backwards. • All parts removed must be saved to do the reinstallation of the door. •... - Page 8 INSTALLATION 4. Swap the bottom bush and bottom bush cap of the upper door. The bottom bush key must be in the correct position to allow it to be inserted correctly. 5. Remove the lower screws, hinge bracket and adjustable feet from the unit bottom. unscrew unscrew 6.
- Page 9 INSTALLATION 7. Reattach the two lower screws, hinge bracket and adjustable feet to the opposite side of the unit bottom. Loosely secure. screw screw 8. Carefully set the upper door back into place. Ensure the fridge door is aligned horizontally and vertically so that the seals are closed on all sides before finally tightening the top hinge.
-
Page 10: Cleaning Before Use
INSTALLATION Cleaning Before Use Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water using a ‘wrung-out’ sponge or cloth. Wash the shelves and salad bin in warm soapy water and dry completely before replacing in the unit. Clean the exterior of the unit with a damp cloth. -
Page 11: Product Overview
Product Overview Internal Light and Thermostat Control Dial Adjustable Upper GlassShelves Door Shelf Salad Bin Cover Salad Bin Lower Door Shelf Levelling Feet Egg Tray... -
Page 12: Operation
Operation Switching On Your Unit 1. Before connecting the unit to the mains supply make sure that the thermostat control dial is set at position OFF. This is located on the right side of the cabinet. Connect the mains cable to the mains socket. 2. -
Page 13: Tips For Keeping Food In The Unit
Tips for Keeping Food in the Unit • Cooked meat/fish should always be stored on a shelf above raw meat/fish to avoid bacterial transfer. Keep raw meat/fish in a container which is large enough to collect juices and cover it properly. Place the container on the lowest shelf. •... -
Page 14: Maintenance
Maintenance Changing the Internal Light 1. Before carrying out the bulb replacement always adjust the thermostat control dial to Position 0, then disconnect the mains supply. 2. While holding the lamp cover place coin between lamp cover lip and internal wall of the refrigerator and twist the coin. - Page 15 Product fiche concerning the "COMMISSION DELEGATED REGULATION (EU) No 1060/2010" Trade mark: LEC Moder Identifier: L5017W/S/B Category of the household refrigerating appliance model: Refrigerator Energy efficiency class: A+ Energy consumption 114 kWh/annum, based on standard test results for 24 hours. Actual energy consumption will depend on how the appliance is used and where it is located.
- Page 17 0344 8153737...
